    The Complete ADC conversion Library Course In PIC

    Posted By: naag
    Date: 30 Jul 2020 01:31:33
    The Complete ADC conversion Library Course In PIC

    The Complete ADC conversion Library Course In PIC
    MP4 | Video: AVC 1280x720 | Audio: AAC 44KHz 2ch | Duration: 32M | Lec: 6 | 331 MB
    Genre: eLearning | Language: English

    ADC Library

    ADC (Analog to Digital Converter) module is available with a number of PIC MCU modules. ADC is an electronic circuit that converts continuous signals to discrete digital numbers. ADC Library provides you a comfortable work with the module.

    Library Routines


    ADC_Init
    ADC_Get_Sample
    ADC_Read


    ADC_Init

    This routine initializes PIC’s internal ADC module to work with RC clock. Clock determines the time period necessary for performing AD conversion (min 12TAD).

    Requires MCU with built-in ADC module.

    Example: ADC_Init(); // Initialize ADC module with default settings

    ADC_Get_Sample

    unsigned ADC_Get_Sample(unsigned short channel);

    Returns 10 or 12-bit unsigned value read from the specified channel (MCU dependent).
