Master Zuken E³.series – Complete Wire Harness & formboard
Master Zuken E³.series – Complete Wire Harness & formboard
Published 8/2025
Duration: 4h 37m | .MP4 1920x1080 30 fps(r) | AAC, 44100 Hz, 2ch | 2.85 GB
Genre: eLearning | Language: English
Published 8/2025
Duration: 4h 37m | .MP4 1920x1080 30 fps(r) | AAC, 44100 Hz, 2ch | 2.85 GB
Genre: eLearning | Language: English
"Harness Routing, Layout Creation, and Formboard Techniques – From Zero to Expert"
What you'll learn
- Understand the Zuken E³.series interface
- Create and modify electrical database, formboard drawing
- Design and route complete wire harnesses
- Apply best practices for electrical design
Requirements
- Zuken software
Description
Master Zuken E3 Formboard 2D Wire Harness Design – From Basics to Advanced
This course is a complete, hands-on guide to designing professional wire harnesses using Zuken E3 Formboard. Whether you are a beginner exploring the software for the first time or an experienced engineer looking to refine your skills, you’ll learn step-by-step how to create, route, and optimize 2D harness designs for real-world applications across multiple industries.
We begin with the fundamentals — creating connectors, symbols, and reusable templates — before moving into layout preparation, component placement, and structured wire routing. You will then progress to advanced techniques such as multi-core and twisted pair cable routing, applying cable protection with braiding, loom, conduit, and PVC tubes, and customizing wire colors, gauges (AWG), IDs, and connector details to match project requirements.
Practical demonstrations in each lesson show how these methods are applied in automotive, aerospace, heavy machinery, and industrial equipment projects. You’ll also master editing and optimizing designs by modifying terminals, pins, and tables to meet professional documentation and manufacturing standards.
By the end of this course, you’ll have the confidence and skill to produce accurate, industry-ready harness drawings in Zuken E3 Formboard — saving time, improving design quality, and delivering results that meet global engineering standards.
Who this course is for:
- Electrical, Mechanical, and Mechatronics Engineers, Engineering students,Design engineers and CAD technicians,Anyone preparing for a career in automotive, aerospace, or industrial electrical design,Wire harness
