Transformer Design, Sizing, Selection and Calculation

Electrical Engineering Academy: Transformer Design Engineering with Practical Examples

What you'll learn
Transformer Design Overview & Purpose of Selection
Important Codes & Standards
Types of Transformer
Transformer Tank, Winding & Oil
Pre & Post Order Stage Documents
Inspection & Test Plan
Transformer Design: Sizing, Selection and Calculation
Datasheet for Vendor
Requirements
ITI, Degree or Diploma in Electrical Engineering
Scientific Calculator
Excel and Word
Description
After completion of this course

Engineers will be able to work on EPC and MEP Sector

Will be able to design of Substation / Switch Yard

Will be able to do the calculation for HV/ LV and MV

Will be able to work for offer evaluation

Transformer Design Engineering Course

1- Overview

2- Purpose of Selection

3- Important Codes & Standards

4- Types of Transformer

a. Oil Type

b. Dry Type

5- Transformer Tank

6- Transformer Core

7- Transformer Winding

8- Transformer Oil

9- Main Tank Conservator

10- Transformer Marshalling Box

11- Pre Order Stage Documents

12- Post Order Stage Documents

13- Inspection and Test Plan

· Routine Test

a. Measurement of winding resistance

b. Measurement of voltage ratio and check of phase displacement

c. Measurement of short-circuit impedance and load loss

d. Measurement of no-load loss and current

e. Dielectric tests

f. Separate source AC withstand voltage test

g. Induced AC voltage test

h. Partial-discharge measurement

i. Tests on on-load tap-changers

· Type Test

j. Temperature-rise test

k. Lightning-Impulse tests

· Special Tests

l. Switching impulse voltage test

m. Measurement of dissipation factor (tan ) and capacitance

n. Measurement of zero sequence impedance(s)

o. Determination of sound level

p. Measurement of harmonics of the no-load current

q. Measurement of insulation resistance

14- Transformer : Sizing and Selection

15- Transformer Design Calculation

a. Calculation Basis

b. Data & Load

c. Formula Used

d. Results

Who this course is for
Students who want to work in EPC & MEP Sector
Students who want to make career in transformer industry
Transformer Manufacturer
