Often we want to control the speed of a DC motor on demand. This intentional change of drive speed is known as speed control of a DC motor.
Speed control of a DC motor is either done manually by the operator or by means of an automatic control device. This is different to speed regulation – where the speed is trying to be maintained (or ‘regulated’) against the natural change in speed due to a change in the load on the shaft.

Speed control of a DC motor is either done manually by the operator or by means of an automatic control device. This is different to speed regulation – where the speed is trying to be maintained (or ‘regulated’) against the natural change in speed due to a change in the load on the shaft

Therefore speed of the 3 types of DC motors – shunt, series and compound – can be controlled by changing the quantities on the right-hand side of the equation above.

Hence the speed can be varied by changing:
The terminal voltage of the armature, V.
The external resistance in armature circuit, Ra.
The flux per pole, φ.
