Siemens Tia Portal - S71200 PLC-Motion Control

servo motor control with puls-dir signal ( panasonic servo systems example)

What you'll learn
Servo Motor System
Puls+Dir Signal
S7 1200 motion system
S7 1200 Motion command
S7 1200 - Servo wiring
Panasonic servo setting-Panaterm software
Control Servo motor with puls-dir signal
Siemens HMI (Wincc v14)
Siemens Scada(Wincc v14)
Tia Portal V14
More than 2 Hours Video
Control Step motor with puls-dir signal
Requirements
Finished Siemens Tia Portal - S7 1200 PLC -Basic
Finished Siemens Tia Portal - S7 1200 PLC -Basic-2
Tia Portal V14 Software
Basic information about servo and stepper motor
Description
This course about servo motor systems.We will control panasonic servo motor systems with puls and dir signals.

We must use the transistor output PLC. Because of thiswe will use S7 1212 dc/dc/dc. S7 1200 plc can control 4 servo motors with pulse-dir signals.

Pulse signal determines the motor speed and position.100,000 pulses per second sent at Total.

Dir signal determines the direction of rotation of the motor.

Servo motor control ways

1-Puls and dir signal ( for positioning)

2-Analog signals (for speed and torque control)

3-Comminacitons (for positioning , speed and torque control)

We will use option 1 for this course.This method can be used for all servo and stepper motor systems.

We will continue to use real hardware.

Our harware and software list

1-Tia portal v14 pro

2-Wincc V14 Adv.

3-Panasonic panaterm software

4-KTP 400 HMI

5-Siemens S7 1212 DC/DC/DC

6-Panasonic Minas A5 0,4 KW servo system

7-Stepper motor and driver

Will examine all motion commands, and we'll use in our examples.

S7 1200 plc systems have this servo commands

MC_Power
MC_reset
Mc_home
Mc_Halt
MC_MoveAbsolute
MC_MoveRelative
MC_MoveJog

Who this course is for
technician
student
engineer
