Sheet Metal Design Rules For Mechanical Designers

Learn all the design considerations to be kept in mind while designing a manufacturable sheet metal part.

What you'll learn

Sheet Metal Design Considerations; a designer must keep in his mind while design a sheet metal part

Requirements

Although there are no prerequistes for this course but you shoould be aware of any CAD software so that you can practice on rules after watching the class.

Description

If you are planning to become a sheet metal designer or product design, then this is the right course for you. In this course, you will learn about design considerations; a designer needs to keep in mind while designing a product.I have not discussed any sheet metal operation here. I am discussing the consideration which a designer should use so that sheet metal parts do not get deform while manufacturing. Overall, 20 considerations have been discussed in the course. Students can make a list of all the points and use the values when they are designing parts in sheet metal. You will also get a detailed lecture on flat length so that your basics are clear before proceeding with the other design features.Pre-requisites -   There are no pre-requisites for this course; you should know about only CAD software as without any CAD knowledge you will not be able to practice.Course Outcomes-  After completing this course, you would have detailed knowledge of 1. Calculating Flat Length2. Extruded Holes3. Holes4. Bends5. Embossment6. Cut7. Hem8. Notch9. Dimples10. Gusset11. Counterbore12. Countersinks13. Lance14. Burrs15. Offset bends16. Knife Edges17. Fillets18. Uniform Thickness19. Welding20. Stiffener21. PlatingWho can join?1. Mechanical Engineers2. Product Designers3. Industrial Designers4. Manufacturing Engineers5. Sheet Metal Designers

Overview

Section 1: Flat Length of a Sheet

Lecture 1 How to calculate flat length of a sheet?

Section 2: CAD Considerations

Lecture 2 Extruded Holes

Lecture 3 Holes

Lecture 4 Bends

Lecture 5 Embossments

Lecture 6 Curls

Lecture 7 Hems

Lecture 8 Notch

Lecture 9 Dimple

Lecture 10 Gusset

Lecture 11 Counterbores and Countersinks

Lecture 12 Lecture 11 - Ribs

Lecture 13 Lecture 12 - Lance

Lecture 14 Lecture 13 - Tabs

Lecture 15 Lecture 14 - Burring Hole

Mechanical Engineer,Product Designer,Sheet Metal Designer,Manufacturing Engineer
