Piperack piping and Stress Analysis

Piperack Layout & Stress Fundamentals

What you'll learn
Pipe rack configuration design
Interconnecting diagram
Design Considerations & Battery Limits
Stress Analysis basics & Fundamentals
Requirements
Willing Ness to Learn
Description
Pipe rack is integral part of any process plant, there are many ways to perform the design, but the basic concepts behind the same is always same. This course covers a lot fundamentals along with the stress analysis basis.

Following modules have been covered and explained in systematic way. All the design considerations have been captured and explained in such a way that whole design section is covered.

Major topics under Layout are:

•Inputs required

•Conceptual Design

–Interconnection Diagram

–Calculating rack width and no. of Tiers from Interconnection Diagram

–Operational/Maintenance/Access requirements

–Deciding the Elevation of transverse beams

Design Considerations

•Guidelines for placing lines on Piperack

Battery Limit Configurations have been explained

•Supporting & Flexibility requirements

•Equipment on Piperack

•Platforms above Piperack

Stress Analysis: Complete content is prepared by Mr. Anup Dey (Special Thanks for valuable contribution)\

Various concepts related to Stress Analysis keeping in view the Piperack piping have been captured and explained in detail.

Actual modelling in CAESAR II is done and explained in detail w.r.t. industry practices and various codes & standards.

Following major activities have been captured

Setting Ground Work

Documents/Input Required

Input parameters in Caesar

Settings Unit Systems

·Codes & Standards used

Step By Step Modelling

Various tools of Caesar II

Pipeline, Fittings, Supports

Best Practices while modeling/Analysis

Modeling of Piperack piping

Along with above following topics have been covered

Expansion loops

PSV piping analysis

The Complete course covers most of the Layout & Stress Analysis related concepts, step by step modelling in Caeser-II has been defined which every piping engineer should understand, hope this adds value to the knowledge. Happy Learning!!

Who this course is for
For All levels
