Node-Red Design With Siemens S7-1200 Plc

Node-Red Design With Siemens S7-1200 PLC

What you'll learn

How to Design Node-red Dashboard , MQQT Broker , OPC UA Server, SQL database management.

For beginner can take 2 week for proper understanding.

Test and simulate the application before implementing in plant.

Use attached project for implementing a Logical project for your plant.

Requirements

Basic Knowledge of Siemens PLC

Description

Hello Friends ,Node-red is worldwide best tool used for Data management and Data visualization.  Nowadays Node-red is also accepted in Many industries as there main dashboard. Node-red is cost effective tool as it is developed by IBM for free open source.In this course Siemens S7-1200 PLC is used for many ways communication to node-red . I have use Direct nod communication , MQQT broker , OPC Communication to get data to and from. For MQQT broker I am using Eclipse MQQT broker.For OPC UA Communication I have Programmed Siemens S7-1200 PLC as OPC UA Server. Also Informed How we can test OPC UA Data in UA expert software. In this we have used ngrok software to transfer our data from localhost to internet.Also explain how we can control our MQQT broker through mobile , which can be directly used for IOT application.Also explain how we can provide Node-red editor and Dashboard username and password and can be used as best security option. For Node-red database management I have used  microsoft SQL Server and  Microsoft SQL Management Studio.Also explain how to install SQL database  and all other function like create database , create Table , insert , update  is also explain.For data visualization I have used dashboard node which has wide range of feature. This course will very useful in the field of IOT application.

Overview

Section 1: Installation and Configuration of Software Packages

Lecture 1 01.Installing Node-Red on Windows 11 PC

Lecture 2 02.Install Eclips MQQT Broker

Lecture 3 03. Test the MQQT Broker using MQQT Box

Lecture 4 04. how to manage and Install Node-Red Palette

Section 2: Configuration and Communication between Node-Red and Siemens S7-1200

Lecture 5 05. S7-1200 PLC Configuration

Lecture 6 07. Read PLC Data to Node-Red

Lecture 7 07. Write Node-red Data to PLC Data

Lecture 8 09. S7-Comm Read Node Configuration

Lecture 9 10. S7-Comm Write Node Configuration

Section 3: Configuration and Communication between Node-red and SQL

Lecture 10 11. Detail installation and configuration of Microsoft SQL Server

Lecture 11 12. Configure SQL Database and Table

Lecture 12 13. Insert the Data From Node-red to SQL Server

Lecture 13 15. How to set ID in SQL Server Database

Lecture 14 16. Retrieve Data from SQL to Node-red

Section 4: MQQT Broker

Lecture 15 17. MQQT Broker _Subscriber and Publisher Node Testing and Configuration

Lecture 16 MQQT Broker With SQL Server

Lecture 17 19.MQQT Beoker Username and Passwrod

Lecture 18 20.. Configure and test S7-1200 as a MQQT Client

Lecture 19 21. Publish and Subscribe the data between S7-1200 and Node-red

Lecture 20 22. WinCC Professional to node-red using string conversion method

Lecture 21 23. APPLICATION _subscribe and publish data from Android APP to s7-1200 PLC

Section 5: OPC-UA Server Application

Lecture 22 24. Manage Pallete and Introduction to OPC UA

Lecture 23 25. Configure and Activate OPC UA Server in S7-1200

Lecture 24 26. Configure and Test Node-red with OPC UA Server

Section 6: Dashboard

Lecture 25 Dashboard _Switch_Guages_LED_Slider_Text Input

Lecture 26 Use of Dropdown Node

Lecture 27 Dashboard Notification

Lecture 28 Momentary Push-Button using Template

Lecture 29 Username and Password to Node-red Editror

Lecture 30 Username and Password to Node-red Dashboard

Lecture 31 Dashboard Numeric Input

Lecture 32 Node-red Dashboard localhost to internet

Section 7: Extra Lecture – OPC UA

Lecture 33 Kepserver EX as OPC UA Server

Lecture 34 Kepserver OPC UA with Node-red

Beginner For Node-red learner and IOT application developer.
