Managing Big Facades Using Rhino.Inside

Learn how BIG designs and manage a Facade System using Rhino.Iniside.

What you'll learn
Description
In collaboration with Why take this course?
In this course, Olliver Thomas teaches you how to manage facade design options using Rhino.Inside, Revit, and Grasshopper. Oliver is a veteran BIM computational design specialist working at BIG. He is in a unique position where he works with multiple teams to implement BIM strategies and workflows using the latest computational design tools. After testing Rhino.Inside at BIG and being impressed with the potential it offers, it was quickly rolled out as one of the core tools for future projects. Start learning Rhino.Inside today, upgrade your skills and learn from the best!
Learn why Rhino.Inside is a game-changer for interoperability
Rhino.Inside makes the transfer of information between Rhinoceros 3D and Autodesk Revit quick, easy, and intuitive. It’s a real game-changer. Rhino.Inside is an open-source project which allows you to run Rhino and Grasshopper within other programs such as Revit. It takes literally a push of a button to get your geometry into Revit from Rhino and vice versa. The power of Rhino.Inside is its simplicity, it doesn’t take a computational design expert to master it.
Improving your Interoperability skills with Rhino.Inside will bring significant improvements in efficiency across your projects. Knowing these skills have a major positive impact on your organization.
The San Fransisco CREAMERY by BIG as a case study
This project is an interesting case study to use computational design tools such as Rhino.Inside to design, check, and populate a facade with various panel options. You’ll use Rhino to create various panel options and use Grasshopper to quickly populate the facade. When satisfied with the result, Rhino.Inside is used to get the panel into Revit for manual fine tuning and family creation. As a final step, Rhino.Inside is used to quickly populate the facade and see the result.

Learn the facade option design strategy for interoperability used by BIG
In the first lessons, Oliver explains the workflows used by some of the designers at BIG to set up a facade option design strategy. Rhino is used to explore various panel options and Grasshopper to populate the facade to see the overall look. You’ll get valuable insights to what degree of detail the panel is modeled and when it is time to get the panel into Revit for fine tuning.

Transfer facade options from Rhino to Revit in a few simple steps
When a facade option is chosen, we move to Revit. Rhino Inside is used to get the rough panel geometry neatly imported into Revit. In Revit, we continue to fine tune the panel and take a look into typical cases like a regular and corner panel.

Update your facade quickly and easily with new design information
Designing buildings is a dynamic process. Sometimes the client has extra demands and the program changes. In the final lessons, Rhino and Grasshopper are used to update the massing and consequently the facade. Rhino.Inside is then used to quickly update the Revit model with the new information.

Overview

Lecture 1 Introduction to the course

Lecture 2 Developing the massing

Lecture 3 Developing the base script

Lecture 4 Aligning facade surface orientations

Lecture 5 Creating the design output script

Lecture 6 Creating the Revit output script

Lecture 7 Developing the curtain panel family in Revit

Lecture 8 Facade generation in Revit using Rhino.Inside

Lecture 9 Re-generating our panels

Lecture 10 Updating our panel information
