Steam Boilers, Steam & Condensate Systems 16Hour Masterclass

A comprehensive guide to design operation optimization and troubleshooting of boiler plants steam and condensate systems

What you'll learn

Design and optimize steam systems for safe, efficient, and reliable operation in process plants

Calculate and measure steam consumption across various plant items, equipment, and processes

Size and layout steam distribution pipes and manage steam mains, ensuring proper drainage and expansion control

Understand the properties of steam, including superheated steam and steam quality, and apply this knowledge to heat transfer applications

Select and maintain steam traps and strainers to ensure efficient steam system operation and reduce energy loss

Identify potential hazards of steam and implement preventive measures to ensure system safety

Operate and troubleshoot steam boilers based on an in-depth understanding of boiler design, construction, and controls

Optimize boiler efficiency through best practices in combustion, water treatment, and heat recovery systems

Manage boiler water levels and implement automatic level control systems, alarms, and safety measures

Recover and reuse condensate effectively, reducing energy consumption and operational costs

Design and size condensate return lines, avoiding pressure drops and ensuring smooth condensate flow

Pumping and lifting condensate efficiently, minimizing energy loss and ensuring proper system operation

Apply real-world troubleshooting techniques to resolve common issues in steam, boiler, and condensate systems

Utilize engineering best practices to improve the overall performance and safety of steam and condensate systems

Requirements

There are no strict prerequisites for enrolling in this masterclass. Whether you are an experienced engineer or new to steam systems, boilers, and condensate recovery, this course is designed to accommodate learners of all levels

What you need to succeed :

A basic understanding of industrial operations is helpful, but no prior knowledge of steam or condensate systems is required

An interest in improving energy efficiency and operational safety in plant environments

A desire to learn practical, real-world skills from experienced professionals

This masterclass is structured to guide you step-by-step through foundational concepts and gradually introduce more advanced techniques, making it accessible for beginners while still being valuable for seasoned professionals looking to enhance their expertise

With this flexible approach, anyone interested in improving their knowledge of steam, boiler, and condensate systems can confidently join and succeed in the course

Description

Unlock the full potential of your steam and condensate systems with this 16-hour masterclass packed with real-world case studies, engineering best practices, and extensive visuals.Designed and delivered by industry experts with hands-on experience, this course is perfect for engineers, plant managers, and technicians aiming to master the intricacies of steam systems, boilers, and condensate recovery.Why take this course?Steam and condensate systems are essential to the efficiency, safety, and productivity of process plants. This masterclass will equip you with the knowledge and skills to design, operate, maintain, and optimize these systems to enhance energy efficiency and ensure trouble-free operations. Throughout the course, you’ll be guided by in-depth technical descriptions, detailed animations, step-by-step instructions, and numerous solved problems that emphasize key learning points.PART 1: Steam SystemsIn this part, we will dive deep into steam systems, which form the foundation of efficient plant operations. You will learn how to design, size, and maintain steam systems, ensuring they are optimized for safety, energy efficiency, and operational excellence.Topics include:Steam plant overview and the properties of steam (including superheated steam and steam quality)Heat transfer principles in steam and condensate systemsEstimating and measuring steam consumption for process equipment, tanks, and plant itemsPipe sizing for steam distribution and effective drainage strategiesThe importance of steam traps, strainers, and understanding steam hazardsBy the end of Part 1, you’ll have a solid understanding of how to manage your steam distribution system from the boiler to the point of use and through condensate recovery.PART 2: Steam BoilersThis section is dedicated to steam boilers, focusing on the design, control, and efficient operation of these critical systems. Whether you're dealing with shell boilers or other boiler types, this module offers the insights needed to ensure reliable performance and safety.Topics covered include:Overview of the boiler house and boiler efficiencyBoiler fittings, mountings, and steam headersFeedwater conditioning, controlling TDS (Total Dissolved Solids), and heat recovery from boiler blowdownManaging water levels and automatic level control systems in steam boilersTroubleshooting guidelines and operation best practices in accordance with ASME and other standardsIn this part, you’ll gain valuable insights from real-world industrial scenarios, learning what worked and what didn’t during boiler startup, debottlenecking, and troubleshooting.PART 3: Condensate SystemsEfficient condensate recovery is key to maximizing the energy potential of your steam systems. In this final part, you’ll explore everything from condensate return line layouts to pumping methods and system optimization.Topics include:Condensate recovery strategies to reduce energy wasteBest practices for layout and sizing of condensate return linesPumping condensate from vented receivers and how to lift condensate over obstaclesEnsuring efficient condensate system operation and troubleshootingBy mastering these concepts, you’ll be able to design and operate condensate systems that maximize plant efficiency while minimizing downtime and operational costs.Key Features of the Masterclass:Real-world case studies showcasing actual plant scenariosExtensive visuals and animations to simplify complex topicsEngineering best practices with downloadable resources and design templatesNumerous quizzes and solved problems to reinforce learning and ensure concept masteryDelivered by experienced engineers with hands-on expertise in steam systems and boilersBy completing this masterclass, you will gain the confidence and expertise needed to manage and troubleshoot your steam, boiler, and condensate systems effectively. This course will help you avoid costly mistakes and ensure the safe, efficient, and reliable operation of your plant.Enroll now and take the next step in your professional development !WR TrainingSpread the wings of your knowledge

Overview

Section 1: Steam plant overview

Lecture 1 Introduction

Lecture 2 The boiler

Lecture 3 Feedwater

Lecture 4 Blowdown

Lecture 5 Level control

Lecture 6 The flow of steam to the plant

Lecture 7 Steam quality

Lecture 8 Pressure reduction

Lecture 9 Steam at the point of use

Lecture 10 Process control

Lecture 11 Condensate removal

Lecture 12 Before you proceed to the next section

Section 2: What is steam ?

Lecture 13 Introduction

Lecture 14 Triple point

Lecture 15 Ice

Lecture 16 Water

Lecture 17 Steam

Lecture 18 Enthalpy of evaporation

Lecture 19 Enthalpy of saturated steam

Lecture 20 Saturated steam tables

Lecture 21 Dryness fraction

Lecture 22 The steam phase diagram

Lecture 23 Flash steam

Lecture 24 Mass and energy conservation

Lecture 25 Before you proceed to the next section

Section 3: Superheated steam

Lecture 26 Introduction

Lecture 27 Superheated steam tables

Lecture 28 Superheated steam for heat transfer applications

Lecture 29 Sizing example

Lecture 30 The effect of reducing steam pressure

Lecture 31 The Mollier chart

Lecture 32 Steam expansion through a turbine

Lecture 33 Before you proceed to the next section

Section 4: Steam quality

Lecture 34 Introduction

Lecture 35 Correct quantity

Lecture 36 Correct temperature and pressure

Lecture 37 Air and other incondensable gases

Lecture 38 Other sources of air in the steam and condensate systems

Lecture 39 Cleanliness of steam

Lecture 40 Dryness of steam

Lecture 41 Waterhammer

Lecture 42 Before you proceed to the next section

Section 5: Heat transfer in steam and condensate systems

Lecture 43 Modes of heat transfer

Lecture 44 The overall heat transfer coefficient "U"

Lecture 45 Temperature difference

Lecture 46 Barriers to heat transfer

Lecture 47 Temperature gradients across layers

Lecture 48 Defining the overall heat transfer coefficient "U"

Lecture 49 Before you proceed to the next section

Section 6: Methods of estimating steam consumption

Lecture 50 Introduction

Lecture 51 Calculation

Lecture 52 Non-flow type applications

Lecture 53 Flow type applications

Lecture 54 Before you proceed to the next section

Section 7: Measurement of steam consumption

Lecture 55 Steam flowmeter

Lecture 56 Condensate pump

Lecture 57 Collecting condensate

Lecture 58 Thermal rating

Lecture 59 Before you proceed to the next section

Section 8: Steam consumption of process tanks

Lecture 60 Introduction

Lecture 61 Energy requirements

Lecture 62 Example of heat consumption of tanks - part 1

Lecture 63 Before you proceed to the next section

Section 9: Heating process equipment with steam coils and jackets

Lecture 64 Introduction

Lecture 65 Submerged steam coils

Lecture 66 Example of heat consumption of tanks - part 2

Lecture 67 Other steam coil layouts

Lecture 68 Control valve arrangement

Lecture 69 Steam jackets

Lecture 70 Before you proceed to the next section

Section 10: Heating tanks by steam injection

Lecture 71 Introduction

Lecture 72 Size of the steam bubbles

Lecture 73 Head of liquid over steam injection point

Lecture 74 Steam bubbles velocity

Lecture 75 Temperature of the liquid

Lecture 76 Sparge pipes

Lecture 77 Example of heat consumption of tanks - part 3

Lecture 78 Steam injectors

Lecture 79 Example of heat consumption of tanks - part 4

Lecture 80 Before you proceed to the next section

Section 11: Steam consumption of pipes

Lecture 81 Introduction to steam consumption of pipes

Lecture 82 Steam mains

Lecture 83 Warmin-up load

Lecture 84 Running-up load

Lecture 85 Before you proceed to the next section

Section 12: Steam consumption of plant items

Lecture 86 Heat exchangers

Lecture 87 More about shell and tube heat exchangers

Lecture 88 More about plate and frame heat exchangers

Lecture 89 Tracer lines

Lecture 90 Sizing tracer lines

Section 13: The boiler house

Lecture 91 Introduction to the boiler house

Lecture 92 Boiler types

Lecture 93 Shell boilers

Lecture 94 Lancashire boilers

Lecture 95 Economic boilers - Two-pass, dry back

Lecture 96 Economic boilers - Three-pass, wet back

Lecture 97 Packaged boilers

Lecture 98 Reverse flame

Lecture 99 Shell boiler summary

Lecture 100 Water tube boilers

Lecture 101 Alternative water tube boiler layouts

Lecture 102 Steam generators

Lecture 103 Economizers

Lecture 104 Superheaters

Lecture 105 Before you proceed to the next section

Section 14: Boiler ratings

Lecture 106 Introduction

Lecture 107 "From and at" rating

Lecture 108 "From and at" rating - Worked example

Lecture 109 kW rating

Lecture 110 kW rating - Worked example

Lecture 111 Before you proceed to the next section

Section 15: Boiler efficiency and combustion

Lecture 112 Introduction

Lecture 113 Heat exported in steam

Lecture 114 Heat provided by the fuel

Lecture 115 Heat losses

Lecture 116 Burners

Lecture 117 Oil burners

Lecture 118 Gas burners

Lecture 119 Burner control systems

Lecture 120 Safety

Lecture 121 Before you proceed to the next section

Section 16: Boiler fittings and mountings

Lecture 122 Introduction

Lecture 123 Boiler name-plate

Lecture 124 Safety valves

Lecture 125 Stop valves

Lecture 126 Feedwater check valve

Lecture 127 Boiler water quality control

Lecture 128 Pressure gauge

Lecture 129 Gauge glasses

Lecture 130 Maintenance of gauge glasses

Lecture 131 Water level control

Lecture 132 Air vents

Lecture 133 Vacuum breakers

Lecture 134 Before you proceed to the next section

Section 17: Steam headers and off-takes

Lecture 135 Introduction to steam headers

Lecture 136 Steam off-takes

Lecture 137 Water carryover

Lecture 138 Warm-up

Lecture 139 Preventing one boiler pressurizing another

Lecture 140 Ensuring proper steam distribution

Lecture 141 Steam header characteristics

Lecture 142 Before you proceed to the next section

Section 18: Water properties

Lecture 143 Introduction

Lecture 144 Hardness and salts

Lecture 145 pH value

Lecture 146 Before you proceed to the next section

Section 19: Water for the boiler

Lecture 147 Introduction

Lecture 148 Good quality steam

Lecture 149 Carryover

Lecture 150 External water treatment

Lecture 151 Ion exchange

Lecture 152 Base exchange softening

Lecture 153 Dealkalisation

Lecture 154 Demineralisation

Lecture 155 Water quality vs treatment process

Lecture 156 Before you proceed to the next section

Section 20: Feedtank and feedwater conditioning

Lecture 157 Introduction

Lecture 158 Worked example

Lecture 159 Feedtank design

Lecture 160 Feedtank construction

Lecture 161 Condensate return

Lecture 162 Flash steam

Lecture 163 Steam injection

Lecture 164 Feedtank vent

Lecture 165 Feedtank take-off

Lecture 166 Miscellanious

Lecture 167 Water level control

Lecture 168 Deaerators

Lecture 169 Summary of feedtank components

Lecture 170 Before you proceed to the next section

Section 21: Controlling TDS in the boiler water

Lecture 171 Introduction

Lecture 172 Boiler water sampling

Lecture 173 Conductivity measurement in the boiler

Lecture 174 Deciding on the required boiler water TDS

Lecture 175 The blowdown rate

Lecture 176 Controlling the blowdown rate

Lecture 177 "Closed loop" TDS control systems

Lecture 178 Before you proceed to the next section

Section 22: Heat recovery from boiler blowdown

Lecture 179 Introduction to heat recovery

Lecture 180 Energy flowrate in blowdown

Lecture 181 Flash steam

Lecture 182 Recovering and using flash steam

Lecture 183 Heat recovery from residual blowdown

Lecture 184 Design considerations

Lecture 185 Summary - Total energy saving

Lecture 186 More about heat exchangers: Plate type

Lecture 187 More about heat exchangers: Shell and tube type

Lecture 188 Before you proceed to the next section

Section 23: Water levels in steam boilers

Lecture 189 Introduction

Lecture 190 Boiler water level

Lecture 191 Methods for detecting water levels in steam boilers

Lecture 192 Level gauge glass

Lecture 193 Magnetic

Lecture 194 Switch contact

Lecture 195 Reed contact

Lecture 196 Optoelectronic switch

Lecture 197 Hydrostatic pressure

Lecture 198 Capillary systems

Lecture 199 Radars

Lecture 200 Radiometric sensors

Lecture 201 Before you proceed to the next section

Section 24: Automatic levels control systems

Lecture 202 ON / OFF control

Lecture 203 Modulating control

Lecture 204 Variable speed feedwater pump

Lecture 205 Single element water level control

Lecture 206 Two element water level control

Lecture 207 Summary of modulating level control

Lecture 208 Before you proceed to the next section

Section 25: Water level alarms

Lecture 209 Introduction to water level alarms

Lecture 210 LOW water alarm

Lecture 211 HIGH water alarm

Lecture 212 Before you proceed to the next section

Section 26: Installation of level controls

Lecture 213 Introduction

Lecture 214 External chambers

Lecture 215 Internal protection tubes

Lecture 216 Before you proceed to the next section

Section 27: Pipe sizing for steam distribution

Lecture 217 Introduction

Lecture 218 The working pressure

Lecture 219 Pressure reduction

Lecture 220 Standards and wall thickness

Lecture 221 Pipe material

Lecture 222 Pipe sizing

Lecture 223 Worked example using the Moody chart

Lecture 224 Oversized steam pipes

Lecture 225 Undersized steam pipes

Lecture 226 Sizing a steam pipe: Pressure factor method

Lecture 227 Sizing a steam pipe: Steam pipeline sizing chart

Lecture 228 Sizing steam pipes on velocity: Principles

Lecture 229 Sizing steam pipes on velocity: Worked example

Lecture 230 Sizing superheated steam pipes

Lecture 231 Sizing a steam pipe: Using formulae and equations

Lecture 232 Before you proceed to the next section

Section 28: Steam mains and drainage

Lecture 233 Introduction to steam mains and drainage

Lecture 234 Piping layout

Lecture 235 Waterhammer (reminder)

Lecture 236 Branch lines

Lecture 237 Drop leg

Lecture 238 How to drain steam mains

Lecture 239 Steam leaks

Lecture 240 Before you proceed to the next section

Section 29: Steam pipe expansion and support

Lecture 241 Allowance for expansion

Lecture 242 Piping flexibility

Lecture 243 Expansion fittings

Lecture 244 Pipe support spacings

Lecture 245 Before you proceed to the next section

Section 30: Steam traps

Lecture 246 Overview of steam traps

Lecture 247 Float traps

Lecture 248 Thermostatic traps

Lecture 249 Thermodynamic traps

Lecture 250 Inverted bucket traps

Lecture 251 Testing of steam traps

Lecture 252 Maintenance of steam traps

Lecture 253 Energy losses in steam traps

Lecture 254 Before you proceed to the next section

Section 31: Strainers

Lecture 255 Overview of strainers

Lecture 256 Wye strainers

Lecture 257 Basket strainers

Lecture 258 Strainer screens

Section 32: Hazards of steam

Lecture 259 Introduction to hazards of steam

Lecture 260 Purging with steam

Lecture 261 Blanketing with steam

Lecture 262 Hazards from condensing steam

Lecture 263 Water from steam

Lecture 264 Thermal expansion

Lecture 265 Stresses in equipment

Lecture 266 Before you proceed to the next section

Section 33: Condensate recovery

Lecture 267 Introduction to condensate recovery

Lecture 268 Calculating the amount of flash steam from condensate

Lecture 269 Live steam / Flash steam

Lecture 270 Why return condensate and reuse it ?

Lecture 271 The financial value or returning condensate

Lecture 272 Before you proceed to the next section

Section 34: Layout of condensate return lines

Lecture 273 Introduction to layout of condensate return lines

Lecture 274 Drain lines to steam traps (1/3)

Lecture 275 Sizing a drain line to a thermostatic trap

Lecture 276 Drain lines to steam traps (2/3)

Lecture 277 Drain lines to steam traps (3/3)

Lecture 278 Discharge lines from traps

Lecture 279 Common return lines

Lecture 280 Draining into flooded lines

Lecture 281 Discharge lines at different pressures

Lecture 282 Before you proceed to the next section

Section 35: Sizing condensate return lines

Lecture 283 Introduction

Lecture 284 Sizing drain lines to traps

Lecture 285 Sizing drain lines to traps - Worked example

Lecture 286 Sizing discharge lines from traps

Lecture 287 Factors affecting the two-phase flow

Lecture 288 Condensate pipe sizing chart

Lecture 289 Sizing for falling discharge lines - Worked example

Lecture 290 Sizing for rising discharge lines - Worked example

Lecture 291 Sizing for vented discharge lines - Worked example

Lecture 292 Common return lines - Falling lines

Lecture 293 Common return lines - Rising lines

Lecture 294 Falling common line - Apply your knowledge

Lecture 295 Rising common line - Apply your knowledge

Lecture 296 Before you proceed to the next section

Section 36: Pumping condensate from vented receivers

Lecture 297 Introduction to pumping condensate from vented receivers

Lecture 298 Pumping terminology

Lecture 299 Cavitation in centrifugal pumps experiment

Lecture 300 Head exercise with a positive displacement pump

Lecture 301 Centrifugal condensate pumps

Lecture 302 Sizing a condensate recovery unit

Lecture 303 Sizing the discharge pipe for a condensate recovery unit

Lecture 304 Positive displacement condensate pumps

Lecture 305 More on positive displacement condensate pumps

Lecture 306 Pump application

Lecture 307 Sizing a mechanical condensate pump

Lecture 308 Condensate pump sizing exercise

Lecture 309 Sizing the discharge pipe for a mechanical condensate pump

Lecture 310 Sizing the discharge pipe for a mechanical condensate pump - Worked example

Lecture 311 Sizing the discharge pipe for a mechanical condensate pump - Worked example 2

Lecture 312 Assessing a larger pump and a smaller delivery line

Lecture 313 Condensate velocities

Lecture 314 Best practices for long delivery lines

Lecture 315 Before you proceed to the next section

Section 37: Lifting condensate

Lecture 316 Lifting condensate from a steam main

Lecture 317 Contaminated condensate

Lecture 318 Before you proceed to the next section

Section 38: Downloadable resources

Lecture 319 Download me

This masterclass is ideal for a wide range of professionals looking to deepen their understanding of steam systems, boilers, and condensate recovery. You will find the course content valuable if you are:,Engineers and Technicians working in process plants, power generation, petrochemicals, or any industrial sector that relies on steam systems for energy and production,Plant Managers and Operators responsible for the operation, maintenance, and optimization of steam and condensate systems and looking to improve plant efficiency and reduce operational costs,Maintenance Personnel tasked with troubleshooting and maintaining steam boilers and condensate systems, ensuring their reliable and safe operation,Energy Efficiency Specialists focused on maximizing energy recovery and minimizing waste through effective condensate recovery and steam system optimization,New Engineers or Graduates looking to build a strong foundation in steam and condensate systems, preparing for a career in industries like refining, chemical processing, or power generation,Anyone Seeking Practical Knowledge in steam, boiler, and condensate systems, even without prior experience, to boost their technical skills and understanding of industrial energy systems,Whether you're a beginner aiming to grasp the fundamentals or an experienced professional seeking advanced insights, this course offers valuable knowledge and real-world applications that will elevate your skills and enhance your career
