Profibus Pa - From Design To Commissioning

Step-by-Step: Project, startup and diagnostics

What you'll learn

What is PROFIBUS PA

Network topology (for Conventional Areas and Hazardous Areas)

Simulation program for PA Segments

TIA Portal (Siemens) Integration - Using DP/PA and Profinet/PA Coupler

What are GSD, EDDL and FDT/DTM files

Differences between Profibus DP and Profibus PA

Differences between Coupler and Link DP/PA

Good Installation Practices

Requirements

Basic knowlegde of electricity

Basic knowlegde of industrial instrumentation

Industrial Network, in special Profibus DP

Basic knowlegde of PLC systems

Description

This is not a PROFIBUS course in general, but a PROFIBUS PA course! Yes, a course completely focused on the application of networks for process automation interconnecting all instrumentation (for example: temperature transmitters, pressure, positioners, etc.) through this variant of the PROFIBUS DP protocol.PROFIBUS PA networks are gaining more and more space within the industrial automation area, instruments that were analog and transmitted information at 4-20mA, now become digital and provide more information to help with asset management, and how could it be any different? , they begin to communicate on a network.In this course you will understand what Fieldbus networks are and how PROFIBUS PA fits into this name, why it is so important in the technological development of industrial plants and the entire practical part of a project, from its conception in engineering to installation and commissioning of network segments.You will also see all the special care that must be taken during installation and all the tricks to have a stable and functional network with the shortest possible downtime!This is unique material, which you will not find in other general Profibus courses.If you work with this type of network, it's worth checking out all the knowledge available in this course!

Overview

Section 1: Introduction

Lecture 1 Introduction to the Course

Lecture 2 Evolution from HART to Profibus PA

Lecture 3 What is the difference between Profibus DP and PA

Section 2: The Project

Lecture 4 Introduction to the topic: Profibus PA network design

Lecture 5 The components of the PROFIBUS PA network

Lecture 6 Profibus PA basic topology

Lecture 7 Topology for Hazardous areas: FISCO and High power trunk

Lecture 8 Segment simulator - SegmentChecker

Section 3: Good Installation Practices

Lecture 9 Introduction to the topic: Good installation practices

Lecture 10 Cable routing and crimping

Lecture 11 Grounding and termination

Lecture 12 Segment testing and commissioning

Section 4: Integration with the control system

Lecture 13 Introduction to the topic: Integration with the control system

Lecture 14 Integration files: GSD, GSDML, EDDL, FDT/DTM

Lecture 15 Integration of DP/PA gateways into TIA Portal

Lecture 16 Integration of Profinet/Profibus PA coupler in TIA Portal

Lecture 17 Accessing instrument via FDT/DTM interface

Section 5: Diagnosis of PA segments

Lecture 18 Introduction to the Topic

Lecture 19 Understanding Jitter, Unbalance, Noise and Signal Level

Lecture 20 Analyzing a network segment using FDH-1 tool

Lecture 21 Extra Class - Short circuit in segment protectors

Automation Technician/Engineers,Electricity/Electronic Technician/Engineers,People in general interested in industrial automation
