Demystifying Ip Addressing: From Basics To Proficiency

IP Addressing and Subnetting: IPv4 and IPv6

What you'll learn

Will be able to undestand the different types of addresses used in the Networking such as IP address, MAC address and Port Address

IPv4 Classes and range of each type

Identifying given IP is Valid, Invalid, Reserved, Broadcast or Multicast

Designing the network based on the subnets required or number of hosts per subnet

Requirements

Need to download and install Cisco Packet Tracer

No programming and computer hardware experience is required

Description

Networking is used for interconnecting devices to exchange the information. In the networking all the devices communicate with addresses. These addresses are IP address, MAC address and Port address.The destination network will be identified with IP address, Once it is reached destination then it has to contact particular system in that specific network, that can be done with the help of MAC address, Now once the information is reached the system(server) then it has to contact particular service which is running with the help of port address. During this process different devices are interconnected and they use different address types for communication.You will be able to understand the IPv4 Addressing and Subnetting. Assigning a IPv4 address to the systems and testing the communication. Classless Inter Domain Routing(CIDR), IPv6 addressing, Number Systems(Binary, Octal, Decimal, Hexadecimal), Automatic Private IP address(APIPA), Loopback IP, Multicast Address, Broadcast Address and Anycast address in IPv6, MAC address, Port Address. Protocol Data Unit(PDU)-Frame, Packet, Segment.Practical Implementation of these concepts with the help of Cisco Packet TracerHow to connect PC to SwitchesAssigning IP to the PCs and verifying the connectivity.Create a scenario in the packet tracer to test the routingafter calculating subnets you can assign the IP address with custom subnet mask to PCs and verify.Configure the Switch for Remote access using telnetAssign the console password and telnet passwordsAccessing switch through console cableConfigure STPConfiguring VLANStatic Routing and Dynamic Routing with RIPOSI Model and TCP/IP Protocol SuiteDHCP Relay Agent

Overview

Section 1: Introduction

Lecture 1 Introduction

Section 2: Number Systems and Addresses

Lecture 2 Addresses Used in Networking

Lecture 3 Number Systems

Section 3: IPv4 Addressing

Lecture 4 IPv4 Address Classes

Lecture 5 IPv4 Address Classes Continue

Lecture 6 Subnetting in IPv4 Address

Lecture 7 Subnetting Examples

Section 4: IPv6 Addressing

Lecture 8 IPv6 Address Types

Section 5: Switching

Lecture 9 Switch Console Access

Lecture 10 Switch Remote Access

Lecture 11 VLAN and STP

Section 6: Routing

Lecture 12 Router Configuration

Section 7: OSI Model

Lecture 13 Function of each layer in OSI model

Section 8: DHCP

Lecture 14 DHCP Configuration

Section 9: Assessment

Who want to start their career in IT infrastructure Management as Administrator,Install, Configure, Manage and Monitor IT resources
