High-Level Synthesis For Fpga, Part 3 - Advanced

Logic Design with Vitis-HLS

What you'll learn

Using Multi-Cycle design flow to develop sequential circuits in HLS.

Implementing stream communication and computation in HLS

Using FIFO as the synchronisation mechanism between to connected module

Learning how to use an array variable inside an HLS code

Connecting and AND HLS IP to BRAMs in a Vivado project

Working with pointers in HLS

Working with AXI protocol in HLS

Loop pipelining optimisation in HLS

Loop unrolling optimisation in HLS

Loop flattening optimisation in HLS

Loop rewinding optimisation in HLS

Working with the HLS-Stream library in HLS

Handshaking protocol and interfaces in HLS

Requirements

Understanding the basic concepts of C/C++ coding

Understanding the basic concepts of logic operators (e.g., AND, OR, XOR, SHIFT )

“High-Level Synthesis for FPGA, Part 1-Combinational Circuits” Udemy course

“High-Level Synthesis for FPGA, Part 2 - Sequential Circuits” Udemy course

BASYS3 evaluation board

Xilinx Vitis-HLS and Vivado (download Vivado ML Edition or Vivado Design Suite - HLx Editions for Windows or Linux)

Description

This course covers advanced topics in high-level synthesis (HLS) design flow. The goals of the course are describing, debugging and implementing logic circuits on FPGAs using only C/C++ language without any help from HDLs (e.g., VHDL or Verilog). The HLS is recently used by several industry leaders (such as Nvidia and Google) to design their hardware and software platforms. The HLS design flow is the future of hardware design. It quickly becomes a must-have skill for every hardware or software engineer keen on utilising FPGAs for their exceptional performance and low power consumption.This course is the first to explain the advanced HLS design flow topics. It uses the Xilinx HLS software and hardware platforms to demonstrate real examples and applications. Throughout the course, you will follow several examples describing HLS concepts and techniques. The course contains numerous quizzes and exercises to practice and master the proposed methods and approaches.This course is the third of a series of courses on HLS in designing hardware modules and accelerating algorithms on a target FPGA. Whereas this course focuses on multi-cycle design, advanced design, and optimisation techniques in HLS, the other courses in the series explain how to use single-cycle design techniques to develop combinational and sequential logic circuits in HLS.

Overview

Section 1: Prologue

Lecture 1 Introduction

Lecture 2 Course Structure

Section 2: LAB Setup

Lecture 3 Introduction

Lecture 4 Windows Instullation

Lecture 5 Linux Installation

Section 3: Multi-Cycle Design

Lecture 6 Introduction

Lecture 7 Definition

Lecture 8 Multi-Cycle Design vs SCII

Lecture 9 Example

Lecture 10 Handshaking

Lecture 11 Example with vld

Lecture 12 Example with ack

Lecture 13 Example with hs

Lecture 14 Block-Level Handshake

Lecture 15 Exercises

Section 4: Streaming

Lecture 16 Introduction

Lecture 17 Definition

Lecture 18 Streaming FIFO

Lecture 19 Streaming in HLS

Lecture 20 Streaming Example: Vitis-HLS

Lecture 21 Streaming Example: Vivado

Lecture 22 Exercises

Section 5: ArrayInHLS

Lecture 23 Introduction

Lecture 24 Definition

Lecture 25 Array Issues

Lecture 26 BRAM

Lecture 27 Array Read/Write: VitisHLS

Lecture 28 Array Read/Write: Vivado

Lecture 29 Exercises

Section 6: Pointers

Lecture 30 Introduction

Lecture 31 Definition

Lecture 32 Native Pointer Casting

Lecture 33 Pointers on the Interface

Lecture 34 Pointer Arithmetic

Lecture 35 Multi-Access Pointers on the Interface

Lecture 36 Exercises

Section 7: AXI in HLS

Lecture 37 Introduction

Lecture 38 Memory Mapped Interface

Lecture 39 AXI Protocol

Lecture 40 Memory Mapped Output 01

Lecture 41 AXI Addressing in Vivado

Lecture 42 Memory Mapped Output 02

Lecture 43 Memory Mapped I/O

Lecture 44 The m-axi interface

Lecture 45 Exercises

Section 8: Loops In HLS

Lecture 46 Introduction

Lecture 47 Definition

Lecture 48 Loop Unrolling

Lecture 49 Piplelining

Lecture 50 Failure to Pipeline

Lecture 51 (Waveform) Rewinding Pipelined Loops

Lecture 52 Exercises

Section 9: HLS Stream Library

Lecture 53 Introduction

Lecture 54 Definition

Lecture 55 Stream on the Interface

Lecture 56 Blocking/NonBlocking

Lecture 57 HLS Stream Dataflow

Lecture 58 Exercises

Hardware engineers,Software engineers who are interested in FPGAs,Lecturers, researchers, and professors who want to use FPGA-based HLS in lectures, courses or research,Digital Logic enthusiasts
