Design Bridges Using Open Bridge - Level 2 - Intermediate

Learn to model, analyze and design bridges using Bentley Open Bridge - Intermediate guide

What you'll learn

Bridges theory

Steel Girder 2 Span Straight Bridge Model

Steel Girder 2 Span Straight Bridge Model - Using Wizard

Editing Templates for Steel Girder Curved Bridge - Using Wizard

Segmental Bridge Model

Custom Templates

Reporting

Additional Notes -Theory

Requirements

The Design Bridges level 1 is preferable for the basic management of tools and theory

Description

Level 2 of Bentley Open Bridge is an intermediate level guide, where we move one step ahead of the basics of this software. Starting with a short theoretical session, we assume that you have basic know how about bridges, after quick review of some common terms we will get familiar with the interface of Bentley Open Bridge.After brief introduction, we will proceed with an exercise in which we will create Steel Girder 2 Span Straight Bridge Model. In process of making this bridge we will learn multiple procedure like adding a bridge Model, support Lines, bridge Decks, Girders, placing and Modifying Piers, Abutments, Bearings and Barriers.After successful creation of Steel Girder 2 Span Straight Bridge Model using conventional method, we will learn how to make the same using Wizard method which is way more convenient and gets results with just few click and inputs. Furthermore, we will look into field splices. After that you can compare both models at your own convenience.After learning these two techniques for creation of Steel Girder 2 Span Straight Bridge Model, we will learn how to create a curved bridge with custom built templates of deck and pier which lead to our final exercise in which we will learn how to create a Segmental Bridge Model.After completion of these exercises, we will learn how to create our own custom templates and save in library for future usage. Reporting is an important part once we are done with the bridge model so we will learn several tips, tricks and techniques to export different types of reports.At the end of the session you can review the theoretical part where you can know more about the features introduced in the latest updates.#AulaGEO Course conent:Lesson 1 Theory Getting StartedLesson 2 Introduction Lesson 3 Initiating Open Bridge Modler from Open Bridge Designer Lesson 4 User Interface Lesson 5 Importing .tin file (Terrain Model) Exercise : Steel Girder 2 Span Straight Bridge ModelLesson 6 Basic Design Lesson 7 Adding Girders Lesson 8 Adding Cross Frames Lesson 9 Placing Sheer Studs Lesson 10 Placing Pier and Abutment Lesson 11 Placing Bearings, Stepped Cap and Barriers Exercise : Steel Girder 2 Span Straight Bridge Model - Using WizardLesson 12 Adding Bridge Model Lesson 13 Adding Shear Studs Lesson 14 Creating and adding Field Splices Template Exercise : Editing Templates for Steel Girder Curved Bridge - Using WizardLesson 15 Slanted / Curved Deck Template Lesson 16 Custom Hammer Head Pier Template Lesson 17 Creating Curved Bridge Using Custom Templates Exercise : Segmental Bridge ModelLesson 18 Adding Bridge Model Lesson 19 Placing Segments Lesson 20 Reports and Constraints Tool Lesson 21 Modeling Piers, Abutments and Barriers Custom TemplatesLesson 22 Deck Template Lesson 23 Barrier Template Lesson 24 Pier Template Lesson 25 Material Definition ReportingLesson 26 Quantity Report Lesson 27 Input Report Lesson 28 Deck Elevation Report Lesson 29 Bearing Seat Report Lesson 30 Pier Drawing Lesson 31 Section Drawing Additional Notes -TheoryLesson 22 Enhancements in latest versions

Overview

Section 1: Getting Started

Lecture 1 Theory

Lecture 2 Introduction

Lecture 3 Initiating Open Bridge Modler from Open Bridge Designer

Lecture 4 User Interface

Lecture 5 Importing .tin file (Terrain Model)

Section 2: Exercise : Steel Girder 2 Span Straight Bridge Model

Lecture 6 Basic Design

Lecture 7 Adding Girders

Lecture 8 Adding Cross Frames

Lecture 9 Placing Sheer Studs

Lecture 10 Placing Pier and Abutment

Lecture 11 Placing Bearings, Stepped Cap and Barriers

Section 3: Exercise : Steel Girder 2 Span Straight Bridge Model - Using Wizard

Lecture 12 Adding Bridge Model

Lecture 13 Adding Shear Studs

Lecture 14 Creating and adding Field Splices Template

Section 4: Exercise : Editing Templates for Steel Girder Curved Bridge - Using Wizard

Lecture 15 Slanted / Curved Deck Template

Lecture 16 Custom Hammer Head Pier Template

Lecture 17 Creating Curved Bridge Using Custom Templates

Section 5: Exercise : Segmental Bridge Model

Lecture 18 Adding Bridge Model

Lecture 19 Placing Segments

Lecture 20 Reports and Constraints Tool

Lecture 21 Modeling Piers, Abutments and Barriers

Section 6: Custom Templates

Lecture 22 Deck Template

Lecture 23 Barrier Template

Lecture 24 Pier Template

Lecture 25 Material Definition

Section 7: Reporting

Lecture 26 Quantity Report

Lecture 27 Input Report

Lecture 28 Deck Elevation Report

Lecture 29 Bearing Seat Report

Lecture 30 Pier Drawing

Lecture 31 Section Drawing

Section 8: Additional Notes -Theory

Lecture 32 Enhancements in latest versions

Civil engineers,BIM Modelers,Microstation and AutoCAD users,Draft modelers,Civil3D and Revit users
