    Complete Eagle CAD PCB Design: Theory and Practical approach

    Posted By: ELK1nG
    Complete Eagle CAD PCB Design: Theory and Practical approach

    Complete Eagle CAD PCB Design: Theory and Practical approach
    MP4 | Video: h264, 1280x720 | Audio: AAC, 44.1 KHz
    Language: English | Size: 5.95 GB | Duration: 9h 37m

    Complete PCB Design Course for Freshers & Professionals.

    What you'll learn
    Basic Electronics
    Basics of Printed Circuit Board
    Circuit Design and Analysis
    Electronic components and instruments
    Printed Circuit Board Layout Design
    Board Design and Fabrication
    Schematic creation
    Library Creation: Symbol and Package (Footprint Creation)
    Single sided Board Design
    Double sided Board Design
    Multilayer Board Design
    Constraint Management
    Via creation and application
    Blind via, Berried via and Through hole via
    Deign Rules Checking (DRC Errors)
    Gerber creation
    Gerber analysis and improvements
    PCB Manufacturing overview
    Requirements
    Basic Electronics knowledge
    BSc(Electronics)
    Diploma (Electronics or Electrical)
    BE (Electronics or Electrical)
    Master degree in Electronics and Electrical
    Description
    PCB Design and electronics circuit are basements for all type of electronics products. PCBs are derived from the analog and digital circuits which are prepared according to the application required. Printed circuit boards are the main pillars of the Electronics world. Every Electronics products has PCB inside it, from consumer gadgets like computers, smart phones and gaming consoles to industry and even high-tech products.

    Required eligibility

    Diploma in Electrical or Electronics & Communication.

    BE/BTech. in Electrical or Electronics & Communication.

    BSc/MSc in Electronics & Communication.

    ME/MTech. (E&CE) in Communication.

    PCB Design Course Content is given below in brief

    Schematic Design

    Basic Electronics theory.

    Basics of Circuit designing.

    Schematic design preparation.

    Schematic part editing and creation.

    Net list and Net class creation.

    Bill Of Material generation (BOM).

    Electrical Rule Checking.

    Footprint Creation

    Through hole footprint creation.

    Surface Mount Device footprint creation.

    BGA/PGA footprint creation.

    Board Designing

    Board size and shape creation.

    Component placements.

    PCB Routing: 2 to 16 Layer routing.

    Plane creation.

    Design rule checking.

    Gerber generation.

    Skills you gain after the course completion

    Basic Electronics and Electronic components expertise.

    Circuit Designing (Power management circuit designing)

    Circuit Simulation for best understanding of the subject.

    Tools/Software Expertise.

    Basic design module practice up to 4-Layers.

    Advanced design module practice up to 16-Layers.

    Design expertise

    o Assignments consists single and double sided PCB.

    o Assignments consists 2-Layers to 16-Layers design.

    Library Module

    o Symbol and Footprint design for all types of packages.

    High speed placements & routing techniques.

    Power integrity and Signal Integrity analysis.

    Design for Manufacturing, Testing and Fabrication expertise.

    Gerber generation and editing.

    Benefits of choosing PCB Design Course

    Strong hold in basic electronics.

    Circuit Design capability.

    Circuit analysis & ERC.

    Components knowledge.

    Power Supply designing.

    Power Integrity Analysis.

    Multiple PCB-CAD tool expertise.

    Expert in library creation.

    Multi-layer PCB designing.

    Signal Integrity Analysis.

    High speed PCB designing.

    Gerber creation & editing.

    Who this course is for
    Diploma in Electronics and Communication
    Diploma in Electronics and Electrical
    Diploma in Electrical
    Bachelor of Engineering in Electronics and Communication
    Bachelor of Engineering in Electrical and Electronics
    BSc in Electronics
    MSc in Electronics
    MS in Electronics
    Post graduate in Electronics and communication
    Hardware designers
    PCB manufacturer
    Electronic Components engineer
    PCB design and developer
    Circuit designers
    Embedded engineers
    Beginners interested in development of PCB
