Carton Design Using Sheetmetal With Fusion 360

Create your first product container using sheetmetal in Fusion 360!

What you'll learn

At the end of this course, students will have the confidence to create sheetmetal designs and move on with more complex shapes and geometries.

Requirements

This course is intended for students and professionals who would like to step up and expand their design arsenal with sheetmetal. For those who has experience in parametric CAD modeling packages you will be amazed with the fun challenges, tips and tricks that Jomarc is going to share.

Description

Cartons can be made from many materials like plastics and composites. Most of all it is typically made from paperboard. A paper and a sheetmetal has the same characteristic of  “thin sheet”. With this in mind we can utilize the sheetmetal tools of Fusion 360 to create a carton.In this course we are tasked to create a shipping carton in Fusion 360. Utilizing the sheetmetal  tools we will create a double wall corrugated paper - "B,C" flute with thickness of 6mm.Some of the key takeaways are:• Creating and joining sheetmetal flanges.• Creation of sheetmetal flat pattern.• Addition of brand logos and decals.• Creation of 2D drawing based on the 3D model.• Follow along with highly detailed light to moderate instruction.• Course Exercise Files included in every lecture to assist you in starting out where you ended.By the end of this course, you will have the confidence to step-up and model complex packaging designs using sheetmetal tools in Fusion 360.This course is intended for students and professionals who are absolute beginners. In addition, this course is a must for those who are comfortable creating solid bodies. For those who has experience in parametric CAD modeling packages you will be amazed with the fun challenges, tips and tricks that we are going to share.

Overview

Section 1: Introduction

Lecture 1 Welcome

Lecture 2 02 Using the Exercise Files

Section 2: Modeling the Shipping Carton

Lecture 3 03 Creating the reference box

Lecture 4 04 Creating the side walls

Lecture 5 05 Creating the top flaps

Lecture 6 06 Creating the short flaps

Lecture 7 07 Creating the lower flanges

Lecture 8 08 Inserting decals

Lecture 9 09 Creating a 2D drawing

Section 3: Knowledge Check

Lecture 10 10 Final Exam

Lecture 11 11 Exam Solution

Section 4: Conclusion

Lecture 12 Next steps

This course is for beginners and intermediate users who are curious on how sheetmetal in Fusion 360 can be utilized in packaging design. A high degree of interest and desire to learn computer aided design will be highly appreciated.
