Api 600 Ii Clauses Ii Valve Design Ii

API 600 II Gate Valve II Various Clauses II Valve design

What you'll learn
API 600 II Clauses II Valve Design
Requirements
Piping, Oil & Gas awareness
Description
Agenda:Understanding the Scope of API 600List out the Salient featuresUnderstanding the relations between various associated API & ASME stdDetailed discussion on Valve stem typesDetailed discussion on valve wedgesSmall Case study on bonnet thickness calculations with practical examplesVarious applicable clausesTo understand Valve end connections requirementsTo determine the inside diameter of the valveTo understand the wedge & Body guideTo decide wear travelAbout stem designTo design packing box & lantern ringAbout fugitive emissions requirementsValve operator typesValve materials ClausesNon-trim materialsTrim materials

Overview

Section 1: API 600 : Various clauses for Valve design

Lecture 1 API 600 II Scope II Various features II Stem Types II Wedge Design II

Lecture 2 API 600 II Valve Body Thickness

Lecture 3 API 600 II Body Ends II Valve inside Dia II Wedge & Body Guides II Wear travel

Lecture 4 API 600 II Stem Design II Packing Box Ii Latern Ring

Lecture 5 API 600 II Material II Trims II Non-Trims

Section 2: Bonus Section

Lecture 6 Bonus Lecture

Piping Design engineers & designers, Mechanical Engineers
