4G Lte Epc - Advanced Troubleshooting Using Wireshark

Become an industry leading expert at troubleshooting EPC LTE call flows by analyzing captures using wireshark

What you'll learn

4G

LTE EPC Network Architecture

Wireshark

Debugging real world network issues

LTE

Requirements

Basic knowledge of LTE network and Architecture

Description

Ask your self -Are you a LTE engineer who is looking to take their understanding of LTE EPC to the next level ?Do you want to become an expert at identifying and resolving issues ? Do you want to learn how to use Wireshark (industry leading tool for network analysis) for analyzing LTE call flows ?Do you want to learn by analyzing traces and network captures from real networks ?Do you want to ace your LTE interviews by answering trick questions ?If yes, then this course is for you. This course will cover all practical aspects of EPC troubleshooting by analyzing captures from real networks. Unlike other courses and books that offer theoretical background this course relies on real world examples.  We will go through all concepts related to LTE EPC and offer tricks/tips for identifying and resolving network issues. After taking this course you will become an expert at LTE debugging. Course Objectives -Provide solid foundation to troubleshoot real network problems by introducing all necessary concepts.Analyze practical call flows for the following scenarios/Interfaces -Enodeb - MME - S1AP (S1 setup, Heartbeat, enb configuration update etc.)LTE attach/detach (combined/PS only)SGs for CSFB (MT/MO voice and SMS)Default Bearer Creation (S11, S5-C)Authentication (S6a), Cancel Location Update procedure.Role of Diameter Routing Agent in LTEDNS in LTE EPC SGW and PGW selectionProvide tips and tricks for troubleshooting problems in LTE EPC by looking a real network traces using wireshark.Make you a power user of Wireshark for debugging LTE issuesUnderstand all the key parameters and failures using real-network traces

Overview

Section 1: Introduction

Lecture 1 Introduction

Lecture 2 Course Outline

Section 2: EPC Network Architecture

Lecture 3 Network Architecture - S1AP Elementary Procedures

Lecture 4 Network Architecture - S1AP Interface

Lecture 5 Network Architecture - S1-User Plane

Lecture 6 Network Architecture - S11

Lecture 7 Network Architecture - S6a

Lecture 8 Network Architecture - S5/s8

Section 3: Wireshark for LTE troubleshooting

Lecture 9 Wireshark for LTE analysis

Section 4: S1AP - Call Flows

Lecture 10 Call Flows - overview

Lecture 11 Call Flows - S1 Setup

Lecture 12 Call Flows - enodeb Configuration Update

Lecture 13 Call Flows - MME Configuration Update

Lecture 14 SCTP - Hearbeat and Abort procedures

Lecture 15 SCTP Debugging

Section 5: NAS - Call Flows

Lecture 16 NAS - Call Flows - Initial UE Message and PDN Connectivity Request

Section 6: S6a - Call Flows

Lecture 17 S6a - Call Flows - Overview

Section 7: Diameter Routing Agent - DRA

Lecture 18 Diameter Routing Agent

Section 8: S6a - Call Flows - Authentication, Update location and Cancel Location

Lecture 19 S6a - Call Flows - Authentication

Lecture 20 S6a - Call Flows - Update Location

Lecture 21 S6a - Call Flows - Cancel Location

Section 9: NAS - Call Flows - Authentication and ESM information Exchange

Lecture 22 NAS - Call Flows - Authentication and ESM information Exchange

Section 10: S11- Call Flows

Lecture 23 S11 - Call Flows - Create Session Request/Response and Modify Bearer Req/Resp

Lecture 24 S11 - Call Flows - Downlink Data Notification

Section 11: CSFB

Lecture 25 SGs - Call Flows - MO Voice Call

Lecture 26 SGs - Call Flows - MT Voice Call

Section 12: DNS in LTE EPC

Lecture 27 SGW and PGW Selection in LTE EPC

Section 13: Thanks and Congratulations

Lecture 28 You did it!

Lecture 29 Slides

LTE Network Engineers,LTE developers,NOC Engineers,LTE Integration Engineers
