PLC Programming & Touch Panel Introduction to Creation Mitsubishi Electric GX Works2・GT Designer3 GOT2000 series

*This book is volume 3 of Mitsubishi Electric Programming Series I.

What This Book Offers

・Sequence control program can be created
⇒Various control becomes possible by learning the basic writing style

・Can improve PLC/GOT of specific equipment
⇒Learn improvement methods from 4 examples

・Learning how to investigate problems
⇒ Leads to early resolution of problems


Key Topics

Introduction
Chapter 1 Convenient Shortcuts
1-1 Device search "Ctrl + F"
1-2 Device usage list "Ctrl + D"
1-3 Comment, statement, note display "Ctrl + F5, F7, F8."
1-4 Statement list between lines "Ctrl + L"
1-5 Input/delete vertical/horizontal lines "Ctrl + arrow keys."
Exercise 1 (computer operation)
Practice Question 1 Answers
Chapter 2 Basic sequence control program
2-1 Creation of sequence control using a washing machine
2-2 Step 1 Creation of a washing machine automatic operation signal circuit
2-3 Step 2 Create a washing machine sequence control circuit.
2-4 Step 3 Washing machine interlock, creation of temporary stop circuit
2-5 Step 4 Create a circuit for the washing machine's optional course.
2-6 Step 5 Creation of touch panel screen for washing machine operation.
2-7 Step 6 Washing machine manual course circuit/screen creation
Exercise 2 (Bottle transfer sequence control: PLC program)
Practice Question 2 Answers
Exercise 3 (Bottle transfer sequence control: touch panel)
Exercise Question 3 Answers
Chapter 3 Specific examples of PLC/GOT improvement.
3-1 Improvement example 1: Creation of energy-saving operation circuits for equipment/machinery
3-2 Improvement example 2: Creating a maintenance alarm circuit and screen based on the number of operations.
3-3 Improvement example 3: Alarm circuit/screen creation due to reduced operating time.
3-4 Improvement example 4: Creating a circuit and screen that acquires each operation time as a log.
Chapter 4 3 Selections of Program Investigation Methods Useful in Trouble
4-1 Contact coil search "Ctrl + Alt + F7"
4-2 Investigation of defect cause using increment (INC) instruction
4-3 Investigation of defect occurrence step using increment (INC) instruction
At the end
