IMSI DesignCAD 3D Max 18.2
IMSI DesignCAD 3D Max 18.2 | 79,5 MB
This means you can choose to draw in miles, feet, inches, millimeters, centimeters, meters, or kilmoeters. You can also choose to draw in the "classic" unitless mode.
-Units for Current Drawing
-Default Units for New Drawings
-Default Units for Opening Unitless Drawings.
Raster-to-Vector Conversion Tool
DesignCAD 3D MAX Version 15 includes an integrated Raster-to-Vector converter so you can scan in your paper drawings and convert them to editable CAD files saving you hours in design time.
Hatch Pattern Position
The Hatch Pattern Position allows the user to change the seed location from which a hatch pattern is referenced, effectively panning the hatch pattern within its boundary. You now have the ability to add words on Hatch entities and on Double Line entities with hatch pattern fills.
Running Snap Settings
The Running Snap Settings allows the user to turn Running Snaps on or off, and toggle the usage of individual running snap modes. Optional snap modes are:
-GravitySnap
-LineSnap
-MidpointSnap
-IntersectionSnap
-TangentSnap
Hide / Restore Toolbars
Hide / Restore All Toolbars is a handy feature if you need a quick way to increase the drawing area temporarily. It toggles all currently active toolbars on or off.
Modified Dimension Commands
Dimension Commands now allow the user to indicate a units muliplier, making it possible to dimension in some unit other than the drawing's base unit.
-Dimension Diameter
-Dimension Radius
-Dimension Arc
-Dimension Extended
-Dimension Progressive
-Dimension Radius Progressive
And Many More!
