Zuken E3.series 2018 version 19.22(23) Update

Zuken has released an update to E³.series 2018 version 19.00. The latest release contains new and enhanced functionality that further increases productivity throughout all phases of engineering, from design to manufacture.

Zuken E³.series 2018 version 19.22

Designer-33797 Wire is not routed (over signal) with inactive signal equivalence
Designer-33802 New routing executes a pin swap
Designer-33854 When external documents in Multiuser are not checked out and a PDF with external documents is exported, they are without any content in Multiuser and in PDF
Designer-33866 Opening an e3s file on a network drive may lead to a long delay of E3 start
Designer-33867 No automatically new routing in panel of projects from older versions

Zuken E³.series 2018 version 19.23

Designer-06117 Impossible to place conductors to shield symbols in views of graphic nets
Designer-25078 Checkbox settings (activated/deactivated) in dialog "Update components" for components don't remain existing after pressing the "Apply" button
Designer-32123 Segment length can't be adjusted by 'Adjust segment length' from context menu
Designer-32725 No ability to change variants into the default mode and vice versa in project
Designer-33029 Opening a Formboard sheet takes very long with active setting "Show information for option combinations" (performance), caused by dimensioning
Designer-33115 Error: "E -Error in function struct LO_REFSET *__cdecl initlocal_refset(bool), ret = 1" when 'Unique wire name' is selected without setting
Designer-33274 The text type "Project store date" (#1044) is sometimes assigned the wrong date for example in Japan (+ 9h)
Designer-33400 Scrolling freezes over symbols within the device tree
Designer-33510 No display for symbols in the preview window when the assembly is edited
Designer-33561 Connect points of cableducts are incorrectly calculated
Designer-33570 Attribute text template symbol leads to red errors with Error in function int __cdecl at texts with assignment to a conductor end attribute with open connections
Designer-33635 E3.ReportScripts: Wire information not displayed for dynamic cables in the Connection list
Designer-33657 DBE: The version text is reset at symbol type change
Designer-33684 The sorting order in the connection table gets lost when renaming a wire
Designer-33689 It is not possible to move a place field by using the COM-functionality 'Fld.Place' to the same position on another sheet
Designer-33697 When the preview of a sheet takes more than 5 seconds it may occur that E3 doesn't react anymore and the preview is executed again in an infinite loop
Designer-33739 Moving the origin of a model within DBE also moves the position of the physical pins
Designer-33748 Standardize messages that appear when the command 'Purging unused objects…' is used
Designer-33766 Possible crash of E3 when inserting many entries to the connection table
Designer-33796 When deleting a structure node with block and connectors, errors appear and the last action is cancelled
Designer-33864 COM: Attribute.SetValue deletesattribute by using variants/options
Designer-33865 COM: Device.SetAttributeValueVariant sets an additional attribute
Designer-33872 When "All Variants" and "All Options" are active -> No updates when switching options/variants necessary
Designer-33916 Item validation prevents saving without variants/options
Designer-33922 COM: graph.Place -textbox (multiline) cannot be placed at the top of a sheet
Designer-33923 E -CCID:002203: Check Varchs(): Owner is 'Unknown/xxx' but item 'VAR_CH_ITEM/xxx (xxx)' not found in 'varptr' after writing/reading E3D when attributes on owners are no longer permitted
Designer-33924 Assertion FAILED: get_attval(): inv source (xxx) at call up of the variant overview within the device properties when there aredouble divergent attribute values with the same Boolean expression and the same attribute copy
Designer-33933 When copying a splitted block with a pinview, the copy creates a pinview for the original connector instead of a new instance
Designer-33953 Repeated placement of a connector symbol with button D leads to the error 'hnsymb\get_symbol_name_for_pin(), ret = 1' in the schema version
Designer-33966 Incorrect refresh of Formboard tables when switching off options



About Zuken E³.series E3.series is a Windows-based, scalable, easy-to-learn system for the design of wiring and control systems, hydraulics and pneumatics. The out-of-the-box solution includes schematic (for circuit and fluid diagrams), cable (for advanced electrical and fluid design), panel (for cabinet and panel layout), and formboard (for 1:1 wiring harness manufacturing drawings). Integrated with MCAD, E3.series is a complete design engineering solution from concept through physical realization and manufacturing output.


About Zuken. Zuken is a global provider of leading-edge software and consulting services for electrical and electronic design and manufacturing. Founded in 1976, Zuken has the longest track record of technological innovation and financial stability in the electronic design automation (EDA) software industry. The company’s extensive experience, technological expertise and agility, combine to create world-class software solutions. Zuken’s transparent working practices and integrity in all aspects of business produce long-lasting and successful customer partnerships that make Zuken a reliable long-term business partner.

Product: Zuken E³.series
Version: 2018 version 19.22(23) Update Only
Supported Architectures: 32bit / 64bit
Website Home Page : www.zuken.com
Language: multilanguage
System Requirements: PC
Supported Operating Systems: Windows 7even or newer / Server 2008 or 2012
Software Prerequisites: Zuken E³.series 2018 version 19.00 and above
Size: 591.4 mb
