ZWCAD Mechanical 2012.08.30 Build 12079

ZWCAD Mechanical is ZWCAD+ for manufacturing, including all the functionalities of ZWCAD+. With comprehensive libraries of standard-based parts and mechanical tools for design and drafting, ZWCAD Mechanical accelerates the mechanical design process, and helps designers save hours of design and rework. Now designers can spend more time innovating rather than managing workflow issues.

HIGHLIGHTS

Supports local customized enterprise standards and international standards, including ISO, ANSI, DIN, JIS, and GB standards.
ZWCAD Mechanical supports ISO, ANSI, DIN, JIS, and GB drafting environments, enabling designers to maintain a common form of communication. It also provides an easy way to customize your own enterprise standards. The Standards Synchronous Tool ensures the team on the local area network (LAN) to use uniform and up-to-date standards.

Eases your mechanical dimensions with Power Dimension, Multiple Dimension and Dimension Overlay Inspection.
Power Dimension makes dimensioning easier with abbreviated dialog boxes that control and expand only the variables relevant to manufacturing, as well as integrate tolerance and fit list information. With Multiple Dimension, designers can create multiple dimensions with minimal input, resulting in instant groups of ordinate, parallel, or symmetric items that are appropriately spaced.

Automatically generates a BOM with associative Bolloons.
You can quickly draw standard-based balloons, then align and renumber them with ease. It only takes one step to create a BOM (Bill of Materials) which automatically updates when balloons change, ensuring that the data is correct and up-to-date.

Rapidly design using Mechanical Symbols, such as the Surface Texture Symbol, Taper, and Weld.
ZWCAD Mechanical helps you save time and increase design accuracy by providing an abundant amount of mechanical symbols. These mechanical symbols include surface texture symbols, datum identifiers and targets, taper, center hole, weld symbols and more.

Speed up drafting with built-in comprehensive Part Library and PartBuilder.
ZWCAD Mechanical Part Library contains screws, nuts, washers, pins, rivets, springs, and bearings etc. It saves designers hours by taking parts from these libraries, rather than starting from scratch.

Create Section Lines, Direction Symbols, and Detail Views with just a few clicks.
ZWCAD Mechanical allows you to create Section Lines, Direction Symbols and Detail Views from the wizard which only takes a few clicks. Detail Views are updatable when a change is made to the geometry.

Parametrically generate Shafts and Gears.
Designers are able to create Shafts and Gears by inputting the geometric parameters, which greatly accelerates the whole design process.
