    Tekla Structural Designer 2019i SP2 version 19.1.2.16

    Posted By: scutter
    Tekla Structural Designer 2019i SP2 version 19.1.2.16

    Tekla Structural Designer 2019i SP2 version 19.1.2.16 | 315.4 mb

    The Tekla product team is pleased to announce the availability of Structural Designer 2019i SP2. This release includes a number of enhancements and issue resolutions.

    Tekla Structural Designer 2019i Service Pack 2 - Release notes:

    Enhancements & Fixes

    - A number of additional fixes which are not detailed explicitly here are also made to improve general performance and stability. An example of such an issue is listed directly below here:
    . [TSD-5585] - Steel Section Database - an exception could occur when editing the section of steel members in a model when user-defined steel sections had been added to the database with names which did not follow the expected naming format, e.g. a name such as “B1” for a Universal Beam (UB) section rather than “533(210(82))” (entering a non-standard name in the Custom Section dialog would cause a warning to be issued but was not prevented).
    . This issue relates only to release 2019i and subsequent releases.
    - Notifications:
    . [TSD-5123] - Design Process - the "Tekla Structural Designer has finished the design process" pop-up notification message (which was displayed following the Analyse All and Design processes at the bottom right of the screen) has been removed. Instead, a flashing TSD window and taskbar icon will appear at the end of the process, if TSD is not the active window.
    . [TSD-5291] - Error Messages - a message titled “Program error!” with the following text could be issued on closing the program “Tekla Structural Designer encountered error and will terminate. Sorry for the inconvenience.” This was not a cause for concern as it related only to the Tekla Online Side Panel and its underlying application (it would occur only when the panel had been expanded during a program session). Program files and general operation were unaffected. However the message could cause concern and is fixed in this release.
    .. This issue relates only to release 2019i and subsequent releases.

    [TSD-5324] - Panel Loads - Slab Load - when a slab item was moved from one slab to another, any 'Slab' panel load on the first slab was incorrectly displayed on the second slab. While the load was not duplicated in the analysis, it was double counted in the Load Summary check resulting in a loading mis-match being falsely reported. The duplicated graphical display of the load persisted until the model was saved and reopened. This is now corrected so that when a slab item is moved from one slab to another:

    - When the "new slab" option is NOT used, the slab item is assigned the 'Slab' panel load from the new parent slab.
    - When the "new slab" option is used, the slab item is assigned a 'Slab' panel load which is identical to the one on the original parent slab.
    - Note that this issue relates only to release 2019 SP3 (v19.0.3.44) - in which moving of slab items to new/existing slabs was introduced - and subsequent releases.

    [TSD-3158] - Concrete Design - Columns - All Design Codes - for columns with a 2nd layer of reinforcement, the Design Details Longitudinal Bars summary table is now enhanced to list the number of bars in each layer as shown in the picture below: additional text “(X + Y)” is added after the total bar No. and size, where X is the No. of bars in the outer layer and Y the No. in the inner layer.

    - Note that when the principal bar (corner bars in outside layer) size is different to that of the intermediate bars, then X and Y refer only to the intermediate bars. Hence in this case the text would be for example: “4H20 + 12H16 (8 + 4)”

    Tekla Structural Designer 2019i SP2 version 19.1.2.16

    [TSD-2900] - Report - Foundation Reactions - results for column supports were not included in the report for Foundation Reaction items to which a UDA filter was applied. This issue is fixed in this release.

    Tekla Structural Designer 2019i SP2 version 19.1.2.16

    Tekla Structural Designer delivers powerful features for optimizing concrete and steel design, including the ability to quickly compare alternative design schemes, efficiently manage changes and collaborate seamlessly. Regardless of project size or complexity, Tekla Structural Designer's fully automated, productivity-enhancing capabilities enable engineering firms to improve operations, successfully bid more projects and enhance client service.

    Tekla Structural Designer 2019 introduces updates around flexibility and interoperability. The new Core Walls feature enhances real-world simulation and constructible core wall modeling, and new and improved export features focus on data interoperability with Tekla Structures and Autodesk Revit. In addition, the interface and usability for users of Tekla Structural Designer and Tekla Structures have been fine-tuned for a more aligned experience.

    Modeling has never been easier with Tekla Structural Designer. From modeling in 3D or 2D views, to duplicating levels and several built-in tools, Tekla Structural Designer allows you to quickly model any structure. Watch this short video to learn more about some of the tools that will speed up your modeling time.


    Tekla software solutions for advanced BIM, structural engineering and steel fabrication management are produced by Trimble. Tekla software is at the heart of the design and construction workflow, building on the free flow of information, constructible models and collaboration.

    Product: Tekla Structural Designer
    Version: 2019i SP2 version 19.1.2.16
    Supported Architectures: x64
    Website Home Page : https://tekla.com/
    Language: english
    System Requirements: PC *
    Supported Operating Systems: *
    Size: 315.4 mb

    System requirements for effective operation

    CPU: Multi core Intel i5 Series or above, Xeon or AMD equivalent
    Highest affordable performance recommended.
    Memory: 16GB (32GB or more recommended)
    Memory requirements are highly dependent on model content.
    OS: 64-bit Microsoft Windows 7 SP1 / 8.1 / 10
    Operating systems must be running the latest service packs / updates.
    Graphics: 1600 x 900 resolution (1920 x 1080 or higher recommended)
    1GB or higher of dedicated RAM.
    Utilizes HOOPS Visualize, a third party graphics engine available from Tech Soft 3D. To check your adapter’s compatibility visit the HOOPS developer website for HOOPS 20.x, DirectX and OpenGL requirements.
    Disk space: 1GB or more of free space for installation
    Operational disk space requirements are highly dependent on model content.
    Internet connection: Required for access to Online Services and some documentation.
