Siemens Solid Edge ST5 MP06 Update

Product: Solid Edge
Version: 105.00.06.04
Date: 10-Apr-2013

Note: Maintenance Packs are all inclusive and can be installed on top of the base
release or any released Maintenance Pack.

This Maintenance Pack can be installed on top of Version:
105.00.00.102, 105.00.01.15, 105.00.02.06, 105.00.03.03, 105.00.04.03, or 105.00.05.01.


–- Windows 8 –-

Solid Edge ST6 will be the first release to support Windows 8.

Solid Edge ST5 does not support Windows 8. Any ST5 issues that are
specific to Windows 8 or IE 10 cannot be addressed until ST6.

Based on limited testing, most Solid Edge operations (Part, Sheet Metal,
Assembly and Draft) work the same as on Windows 7 and Windows 8. On
Windows 8, we highly recommend installing Solid Edge ST5 to a non-default
location (somewhere other than the default Program Files folder).

In some cases, .NET 3.5 had to be manually activated to use Solid Edge
Tutorials, Insight, and Simulation Express.

Solid Edge License Utility, License Borrowing, Embedded Client, Insight
XT, Web Publisher, and Engineering Reference have known problems on
Windows 8 and will not work successfully with ST5.


––––––––––
End of Release Notes
––––––––––

–––––––––-
Installation Notes:
–––––––––-

After downloading the Maintenance Pack to your machine, unbundle the zip file and
then dbl click on exe to install the Maintenance Pack.

Windows 7 Installation tips: In addition to turning off UAC, right click on the exe
and select "run as administrator" to complete the installation.

Windows 7 Tip: Most of the UAC security conflicts on Win7 can be avoided by installing
Solid Edge somewhere other than the default “Program Files” folder. Install in a location
like c:\SolidEdge\ that the user has full permission to write to.

–––––––––-
End of Installation
–––––––––-

–––––––––––––––––––––––––
This Maintenance Pack addresses the following PRs:
–––––––––––––––––––––––––

===API===

PR 2215035: SweeptSurface.GetTraceCurves method fails to give correct results.
PR 6852467: A crashlog abort in OffSetRangeEditBar::Enable
PR 6868196: ST5 MP delivers incompatible typelib (at least fwksupp.tlb)
PR 1916981: TableRows.Add not adding a row to a Parts List.
PR 6855210: TableColumn.PropertyText returns number rather than name
PR 1932682: unable to open a linked AP doc thru automation
PR 6864678: crash in transfer dialog

===Assembly===

PR 1929734: Bolt connector in SE Simulation places Spider in assembly center
PR 1930860: Crash when displaying a sketch in accelerated display mode
PR 1931109: abort when creating an assembly relationship to an occurrence with an extremely long name
PR 1933294: wrong activated Button in Assemble Command
PR 6811703: assembly axial align relationships not working correctly in some cases
PR 6835674: placing a systems library into an assembly
PR 6836339: Cannot break the copied sketch links cleanly
PR 1928919: Missing some part names if importing JT with Cyrillic characters
PR 1933206: suppressing a relation fails the model
PR 2206720: Pipe disappears on update
PR 6863474: Undo not working correctly when using the assembly Insert relationship.
PR 1931354: locale specific crashes when saving assemblies.
PR 1932893: Assembly file cannot be saved in ST4 but could in V20, Crash is reproducible
PR 2210410: SE crashing after applying a config
PR 1924249: Pathfinder disappearing when right screen is designated as primary
PR 1933270: All on Face does not work with assembly features
PR 1935526: Assembly feature not disappearing after copy then replace.
PR 2213382: Hole options of assembly features changes.
PR 6864186: Replace part turn read-only assembly into writable assembly

===Draft===

PR 1924895: low graphics performance in files with large numbers of objects
PR 1926749: Hatch mapping will be ignored
PR 1934660: Callout value changing when opening a ST3-dft file in ST5
PR 1930438: Crash, while trying to update pasted views of a draft onto a new drawing
PR 1934669: dimension changes by open ST3 draft file in ST5
PR 1935006: opening old draft-file angle dimension changes
PR 6854274: Shading on drawing views not lining up very well
PR 6864081: Cannot copy & paste from one draft file to another draft file
PR 1934573: reproducible crash during copy text using CNTRL+C
PR 6871829: Added code to determine the cause of file corruptions

===Part/Profile/Sheet Metal===

PR 6857479: silent Install using the -s option for Solid Edge 32 bit MP fail to install
PR 1932088: Gage table max 300 rows long
PR 2214304: For auto-mesh some element shown in different color shade.
PR 1914827: problems with Tooltips in different environments after customization
PR 2213853: The plot 'Total Translation (T3)' does not show correct values.
PR 1912273: Unable to mirror a sync sheet metal part to create symmetric model
PR 1933900: FOP Variables deleted
PR 6789153: Edit of Coordinate System position is not updating automatically
PR 6849690: SE Crashes on "Undo"


–-
End
–-
