Siemens Solid Edge 2022 MP01

===API===
PR 10128920: OccurrenceFileName for NX files is incorrect
PR 10063998: Assembly API yielding misplaced graphics

===Assembly===
PR 10092777: Solid Edge crash while Mating a part in an assembly
PR 10173595: Replace of a part being patterned does not replace all parts
PR 10180559: crash when dragging group item to top-node
PR 10133224: Solid Edge termination error… Crash log for development review
PR 10047943: fast locate using Box Display for assemblies
PR 10105225: Incorrect Occurrence property overrides showing up on transferred parts
PR 10199020: SE crashing when working with adjustable parts
PR 10204996: OK-button grayed out after selecting saved setting in Fastener System
PR 8476136: Cancel Isolate does not work in large assembly Preview mode
PR 8476218: Assembly feature locate/selection from NW arrow
PR 8999778: Replace with new part does not support the OnFileNewUI event
PR 9836070: Hole does not cut through the bottom plate

===Draft===
PR 10122641: Unresponsive when placing balloon (Link to Parts List) or when deleting balloon.
PR 10123206: Hole table origin will not be set as desired
PR 10141012: User-defined property with a comma in the name will not be listed
PR 10182012: Crashlog in TC context when importing a block
PR 10174675: SE crash when creating Cutting Plane with 'XY Key-in' selected
PR 10203967: After installation of SE2022 section out broken view is inconsistent
PR 10192460: Crash in Draft at deselecting model and callout in drawing view
PR 10169803: SE BETA - No Thread information on callout for external thread
PR 8481577: Placing drawing view for End Cap
PR 9595087: Section view in draft does not work in bounded plane case

===General===
PR 10149270: Removing Solid Edge version number from UI
PR 10151955: Solid Edge appears to hang when click RMB on pathfinder using Korean UI
PR 10172008: New SE Admin utility contains an error.
PR 10189700: Error while loading *.fld file. …requires installation of FloEFD version…
PR 10168970: Error in DXF exported from Solid Edge 2D Nesting
PR 10194551: Can't input some Polish letters in File properties
PR 9626540: Setting option dialog -> Reset, some NDS setting file name has changed.
PR 8481056: Issues changing the PathFinder width - A lot of Flickering
PR 8483120: Import of PCB results in incorrectly positioned models
PR 8398984: Impossible to save and retrieve used cost values

===Part/Profile/Sheetmetal===
PR 10054110: Symmetric relation was not getting applied between hole circles.
PR 10121323: changing a Variable and set back causes different geometry, regression ST10
PR 10144822: Wireframe display of mesh body disappears after adding B-REP feature
PR 10181678: blocks are unexpectedly listed in the active document of other part documents
PR 10163323: The image inserted in part sketch is not clear
PR 8485836: Fail to flatten this sheet metal part containing Lofted Flange

===Solid Edge Data Management===
PR 10128973: Obsolete file opened via the search is not read-only.

===Teamcenter Integration for Solid Edge===
PR 10166185: Neutral files incorrectly created/uploaded on File Close -> Cancel Save Changes
PR 10163050: ValidateLogin() method throw exception in TCCS mode with https protocol.
PR 10059478: MFK - Numerical revision naming rule not correct

===TechPub===
PR 10193781: Incorrect display of HTML file. the entire assembly is displayed
PR 10196814: Incorrect animation in the published HTML file
PR 10196835: Incorrect playback of HTML file.

===Translators===
PR 9958684: Inventor Migration failed

Operating system requirements and information
Solid Edge 2022 has been certified to run on the following:
- Windows 10 Enterprise or Professional (64-bit only) version 1909 or later
- Internet Explorer 11
- Solid Edge, while not dependent on any other browser, has been certified against other modern and popular browsers like Google Chrome, Microsoft Edge, and Mozilla Firefox.
- Microsoft Office 2019 or Microsoft Office 365 Business.
Note
- Support for Windows 11 will be announced in a Solid Edge 2022 maintenance pack.
- Windows Home Edition is not supported.
- We recommend that you not run Solid Edge on Server operating systems.
- Solid Edge stops certifying new releases against an operating system shortly after Microsoft drops mainstream support for it. Microsoft dropped mainstream support for Windows 7 in January 2015. Microsoft dropped mainstream support for Windows 8.1 in January 2018. As a result, Solid Edge no longer installs on Windows 7 or Windows 8.1.

Hardware system requirements

Recommended system configuration
- Windows 10 Enterprise or Professional (64-bit only) version 1909 or later
- 32 GB RAM or more
- True Color (32-bit) or 16 million colors (24-bit)
- Screen Resolution: 1920 x 1080
Minimum system configuration
- Windows 10 Enterprise or Professional (64-bit only) version 1909 or later
- 16 GB RAM for commercial users and 8 GB RAM for academic users
- 65K Colors
- Screen Resolution: 1920 x 1080
- 7.5 GB of disk space required for installation
Reboot your system after installing Solid Edge or maintenance packs.

Display system requirements and information
For optimal performance, use a professional graphics card designed for CAD applications. For information about cards used in testing Solid Edge and results, see the Graphics Card Certification Matrix on the Support Center Hardware and Software Certifications website.
Note :At least a 2GB graphic card is recommended when working with large assemblies or complex parts.
Running with extremely high screen resolution and color depth increases the memory requirements on the system and may result in apparent performance degradation. For improved performance, lower the resolution and color depth.
When running Solid Edge, if you experience an abnormally high abort rate, parts disappearing, or other graphic anomalies, you may not be using the appropriate graphics driver. For details, see the Hardware and Software Certifications page of the Support Center website.
Also, setting Display Fonts to Large Fonts or Extra-Large Fonts (larger than 96 DPI) may cause some Solid Edge user interface items to not display as intended. To resolve these issues, use Normal Fonts (96 DPI).
Solid Edge uses a widescreen ribbon layout. This ribbon layout is optimal for horizontal screen resolutions set to 1920 or above. Solid Edge automatically detects your resolution and sets the ribbon layout to widescreen starting at horizontal resolutions 1600 and above. Some groups collapse on the right side of the ribbon with resolutions between 1600 and 1920.

Additional Information

Support for High-resolution Monitors
Solid Edge 2022 includes support for bitmaps, controls, and other graphic elements displayed on high-resolution monitors (monitors with resolution greater than 3500 pixels).
When you use a monitor with DPI greater than 170 pixels, we recommend you adjust settings in two locations:
- Set the primary DPI scaling resolution for the entire desktop using the Microsoft Windows Control Panel.
- Adjust the relative sizing of Solid Edge design tools on the Helpers tab in the Solid Edge Options dialog box.
