SI Xchange for Revit Structure 0.5
SI Xchange for Revit Structure 0.5
Win l english | zip | 1Mb
Structural Integrators’ has developed an interface between Autodesk Revit Structure and Bentley Systems’ STAAD.Pro. You can now avoid duplication of effort by exporting your Revit Structure model to STAAD.Pro for analysis and design.
Features
Export capabilities - SI Xchange sends structural Revit elements (beams, columns and braces), as well as boundary conditions, to STAAD.Pro. Both steel and concrete materials and section properties are supported.
Model any way you want - SI Xchange automatically breaks up continuous beams and multi-story columns for analysis in STAAD.Pro.
Name resolution - SI Xchange is preconfigured to resolve standard naming convention differences for steel section profiles, yet is flexible enough to allow for new mappings between profile names for firms that use customized or in-house naming conventions.
Customization - SI Xchange provides configurable options that are saved between sessions.
Reporting - SI Xchange displays a summary of exported members and provides a log file that identifies any problems on export.
