Revit Extention for Autodesk Revit 2013

Revit Extensions for Autodesk Revit 2013 extend the capabilities of Autodesk Revit 2013, Autodesk Revit Architecture 2013, Autodesk Revit MEP 2013, and Autodesk Revit Structure 2013 software in key areas, including structural analysis, modeling, reinforcement, interoperability and construction documentation.

About Autodesk Inc.

Autodesk, Inc., is a leader in 3D design, engineering and entertainment software. Customers across the manufacturing, architecture, building, construction, and media and entertainment industries—including the last 16 Academy Award winners for Best Visual Effects—use Autodesk software to design, visualize, and simulate their ideas before they’re ever built or created. From blockbuster visual effects and buildings that create their own energy to electric cars and the batteries that power them, the work of our 3D software customers is everywhere you look.

Through our apps for iPhone, iPad, iPod, and Android, we’re also making design technology accessible to professional designers as well as amateur designers, homeowners, students, and casual creators. Whether it’s a kid looking to build a new contraption, a seasoned pro sketching out a great new idea, or someone who just wants to amp up their creative output, we’re taking technology originally built for movie studios, automakers, and architectural firms, and making it available to anyone who wants to create and share their ideas with the world.

Since its introduction of AutoCAD software in 1982, Autodesk continues to develop the broadest portfolio of state-of-the-art 3D software for global markets.

Overview

This download contains all previously released Revit Extensions and updates. In addition, this download includes enhancements to the positioning extension and improvements to the reinforcement extensions (dynamic model update, beam reinforcement).
- Reinforcement of Beams
An enhanced feature has been implemented to help detect supports for beams. The support analysis is performed on the bottom plane of a beam which is appropriate for slanted and vertical columns. Additionally, walls are considered as potential supports.

Reinforcement Modules

Enhancements have been implemented to Reinforcement modules and take into account:

- Element selection by the analytical model
The 3d view can be defined as a view with only the analytical model visible in the same manner as the Revit standard template Structural Analysis-Default.rte. It is now possible to select an element and apply reinforcement to it.
- Maintaining rebar settings after modification
After generating reinforcement using Revit Extensions the user can set attributes for generated rebar. Now the following properties: Schedule Mark, Visibility States, Comments and Mark are maintained after modification.
- Dynamic Model Update
After geometric changes to the host element the update of reinforcement is performed. The reinforcement is reapplied using the same parametric data. Settings for this mechanism are set at the project level in Revit Extension Preferences (project settings) and at the element level on the module dialog (element settings). Information about the current action is displayed on the Revit Extension progress bar visible when analysis or generation is in progress. A detailed description can be found in module help files.

visit my blog

Name: Revit Extention
Version: for Autodesk Revit 2013
Creator: http://usa.autodesk.com/
Interface: english
OS: Windows XP / Vista / Seven
Size: 445.8 mb
