Proteus Professional 7.6 SP4

Proteus Professional is a system of circuit simulation, based on models of electronic components made in PSpice. Distinctive feature of the package Proteus Professional is the possibility of simulating the operation of programmable devices: microcontrollers, microprocessors, DSP and others. In addition to the package Proteus Professional is a system design of printed circuit boards. Proteus Professional can simulate the work of the following microcontrollers: 8051, ARM7, AVR, Motorola, PIC, MSP430, Basic Stamp. The library contains the components of reference data.

Supports MC: PIC, 8051, AVR, HC11, MSP430, ARM7/LPC2000 and other common processors. More than 6000 analogue and digital device models. Works with most compilers and assemblers.
PROTEUS VSM allows very reliably simulate and debug fairly sophisticated devices that could contain a few MK at the same time, and even different families in a single device!
You must clearly understand that the simulation of electronic circuits do not exactly repeat the work of a real device. But to fine-tune the algorithm of the MC, this is more than enough. PROTEUS includes a huge library of electronic komponentov.Otsutstvuyuschie model can be done. If a component is not programmable on the manufacturer's website to download it SPICE model and add the appropriate body.

Proteus 7 consists of two main modules:

ISIS - a graphical schematic editor to enter the developed projects, followed by imitation and transfer for the development of printed circuit boards in the ARES. Moreover, after debugging the device can be immediately diluted PCB in ARES that supports auto placement and routing of the existing scheme.

ARES - graphical editor printed circuit boards with built-in library manager and avtotrassirovschikom ELECTRA, automatic placement of components on the PCB.

PROTEUS is a unique opportunity!
USBCONN - this tool allows you to connect to a real USB port.
COMPIM - This component allows your virtual device is connected to REAL COM-port of your PC.

Examples:
- You can connect through the "string" to a free COM-port cell phone and debug the device at MK which should govern them.
- You can connect to the COM-port of any real device with which you created the device will communicate the reality!
PROTEUS VSM - works perfectly with the popular C compiler for MK:
- CodeVisionAVR (for IC AVR)
- IAR (for any MC)
- ICC (for IC AVR, msp430, ARM7, Motorola)
- WinAVR (for IC AVR)
- Keil (IC architecture for 8051 and ARM)
- HiTECH (for IC 8051 and PIC architecture from Microchip)
Program PROTEUS VSM is ideally suited for beginners who have decided to begin the study of microcontrollers.
