Planit Edgecam 2013 R1 SU1

2013 R1 is a release combining new strategies with an improved user interface across many aspects of the software. The strategies will make creating tool paths effortless and the improvements to the user interface will get your result much faster than before.

The latest release of the market-leading Edgecam CNC software features a brand new wire EDM product.

Edgecam 2013 R1 provides an intuitive environment for the comprehensive programming of all wire EDM machine tools. It includes a comprehensive library of proven post-processors and knowledge-based cutting schemes as standard. The new cycles are aware of stock, eliminating air cuts and reducing cycle time.

Users can select from one of the pre-defined machining strategies, such as “Unattended night runs” and “Attended day runs.” Alternatively, they can easily define their own.

Other features include multiple strategies for corner types, different tagging options, the ability to apply roughing and finishing cuts, multiple punches and dies, and a “no core” pocket destruction routine. Another new feature is the “Images and context help” for all options on the Wire and Feature Find command dialogs, which makes the interface more intuitive, and helps users to better understand their purpose.

As well as the new wire EDM function, a number of enhancements gives added value for all Edgecam users:

The industry-leading Waveform Roughing cycle now has the ability to specify a pre-drilled hole as the approach type, ensuring a smoother transition into the material, reducing the cycle time even further.

Another time-saving feature in the Profiling cycle is the new option to specify a chamfer or radius to break sharp corners, eliminating the need for deburring.

A new “Tube” stock type has been added, and the user can now edit stock dimensions and re-pick geometry while retaining the stock shape. Changes to the stock are now considered automatically when regenerating the machining instructions.

In Feature Finder, improved ordering based on a “nearest next” algorithm ensures that features are presented in optimum order for machining. Feature Finder can now also identify U and V shaped groves for subsequent machining.

In Turning, the new Rough Profiling cycle removes material in a series of cuts parallel to the input profile, and is typically used for roughing free form profiles from castings and forgings. It is also useful for cutting materials where it is beneficial to minimise re-entrant cutting as it keeps the tool in contact with the material for longer. The cycle includes intelligent stock entry and exit, as well as being stock-aware to eliminate air cuts and reduce cycle time, along with supporting controller tool offsets and including options to specify a range of different offsets.

Further enhancements have been made to the Edgecam Simulator, enabling the simulation process to be rewound to a previous position in the machining sequence.

Toolpaths are now generated much faster thanks to a new 5-axis 64-bit machining engine running as a separate process, utilising multiple core technology. Background processing of milling cycles in the Mill/Turn environment is now available, meaning the user can carry on working while Edgecam calculates complex toolpaths.

Edgecam is a certified partner for Autodesk Inventor, and 2013 R1 contains a direct interface with Autodesk Vault 2013, allowing users to manage their Edgecam files in it. Work in progress can be tracked, and users can maintain version control over their individual jobs. Edgecam’s Vault menu gives direct access, and users can check part files in and out, and view the change history.

When Edgecam files containing an Inventor model are checked out of the Vault and loaded into Edgecam, any recent changes to the Inventor model are recognised, flagging up the opportunity to update it in the Edgecam part.


Company Profile

Vero Software is a world leader in CAD/CAM development with a proven track record of reliable product delivery. Vero develops and distributes software for aiding the design and manufacturing processes, providing solutions for the tooling, production engineering, sheet metal, metal fabrication, stone and woodworking industries. The companies world-renowned brands include Alphacam, Cabinet Vision, Edgecam, Machining STRATEGIST, PEPS, Radan, SMIRT and VISI, along with the production control MRP system Javelin. Despite the diversity of application, these solutions have one thing in common: they all address the rising challenges of achieving manufacturing efficiencies and bring huge value to the operations where they are deployed.

The company has direct offices in the UK, Italy, France, Japan, USA, Brazil, Netherlands and China, supplying products to more than 45 countries through its wholly owned subsidiaries and reseller network, with more than 135,000 global licenses installed.


visit my blog

Name: Planit Edgecam
Version: 2013 R1 SU1 build 8343
Home: www.edgecam.com
Interface: english
OS: Windows XP / Vista / Seven
Size: 3.0 Gb
