OpenRail Designer 2024 (24.00.02.25)
OpenRail Designer 2024 (24.00.02.25) | 4.9 Gb
The Civil Product Team is pleased to announce the availability of OpenRail Designer 2024 (24.00.02.25) is the complete modeling environment for rail infrastructure, which supports all aspects of detailed track design, including surveying, geotechnical, drainage, underground services, terrain, rail track, rail furniture, and more.
What's new in this update
This release includes bug fixes and minor enhancements built upon the numerous improvements introduced in the 2024 release and fixes to the 2024 Update 1 software. As a minor update, files edited with this version are fully compatible with those edited with the 2024 release without the need for any upgrade or downgrade. Files from older versions are automatically upgraded when opened in this newer release. In addition, 2024 Update 2 automatically evaluates and heals files to ensure they are not impacted by the issue from 2024 Update 1. When a file is detected as previously opened with 2024 Update 1, the software will evaluate and heal it if required. One of four dialogs will appear based on the success of the healing process. This update is built on the same platform as MicroStation 2024 Update 2.
The following summarizes the new features and enhancements in the 2024 Update 2 release of OpenSite Designer, OpenRoads Designer, OpenRail Designer, and OpenRail Overhead Line Designer products, also referred to as OpenX Designer products. Features that are only available in specific products are indicated below.
2024 Update 1 Issues
Fixed the issue causing 2024 Update 1 to be removed, related to circular referencing of DGNs in child or derived profiles. Not all files opened with 2024 Update 1 were affected. 2024 Update 2 now automatically checks and heals affected DGN files when opened, ensuring they are not impacted by the previous issue. When a file is detected as previously opened with 2024 Update 1, the software will evaluate and heal it if required. One of four dialogs will appear based on the success of the healing process.
The file was not affected by the issue
OpenRail Designer 2024 (24.00.02.25)
The file was affected and has been successfully repaired.
OpenRail Designer 2024 (24.00.02.25)
The file was affected and has been repaired except for some objects that need to be recreated if they are still needed. These objects are shown in bold red and grouped for easy identification.
OpenRail Designer 2024 (24.00.02.25)
The file was affected and has been repaired, but some pre-existing issues remain. It should still be fine to use. If problems arise, contact support.
OpenRail Designer 2024 (24.00.02.25)
Geometry Enhancements
- Added ability to modify unacceptable slew values in the Regression Points table.
Drainage and Utilities Enhancements
- Improved performance when computing an analysis scenario. A full update of the model will still be done for the first compute of an analysis scenario in a session, but subsequent computes of that scenario will only update the hydraulic results.
OpenRail Designer 2024 (24.00.02.25)
OpenRail Designer is an all-in-one application that handles a wide variety of complex tasks such as yard/station design, tunnels, corridor modeling, turnout and switch placement, overhead line electrification, site development, sanitary and stormwater network design, subsurface utilities, and production of construction staking reports. You can configure the application to support a wide range of international standards providing you the flexibility and control necessary to deal with real-life design scenarios on global rail infrastructure projects. The application adapts to virtually any rail design and maintenance workflow and is suitable for light rail, metros (transit) heavy rail, high-speed rail, and MAG_LEV projects.
What's new in OpenRail Designer 2024
To help rail designers and engineers deliver safe, resilient and compliant projects on time and within budget, updates in OpenRail Designer 2024 include easier to use geometry, updated regression and cant tools and workflows, a new UK workspace and UK turnout bending method as well as improved reporting and annotation. Check out our playlist to learn more.
Bentley Systems Inc. is a software development company that supports the professional needs of those responsible for creating and managing the world’s infrastructure.
Owner: Bentley Systems Inc.
Product Name: OpenRail Designer
Version: 2024 (24.00.02.25)
Supported Architectures: x64
Website Home Page : www.bentley.com
Languages Supported: english
System Requirements: Windows *
Size: 5.9 Gb
OpenRail Designer 2024 (24.00.02.25)
