Multiframe CONNECT Edition V22 Update 3
Multiframe CONNECT Edition V22 Update 3 | 1.0 Gb
The Multiframe development team is pleased to announce the release of Multiframe CONNECT Edition V22 Update 3 (version 22.03.00.121). This solution helps structural experts check the structure of their vessel to comply with class requirements and optimise it for strength and weight. It can be used for deck grillage, frame, superstructure and mast strength calculations.
Release 22.03 March 2020
- Several New Trimesh Functions - these include extrude, split, assess quality, Boolean operations with groups of closed trimeshes including Union and Intersection, detailed trimesh statistics, trimesh standard shapes,
- Surface Trimming enhancements to simplify detailed models
- Structural Analysis Technology Preview
- COM Automation interface enhancements
- Motions - enhancements
- Multiframe Shape Editor enhancements
• 1060502: Evaluation and Trial licenses are differentiated in the Help | About > Sys Info. dialog. Evaluation licenses must be specifically requested and typically valid for 30 days; trial licenses allow the software to work for the first 7 days of use without the need for activation.
• 1050044, 1030356: A crash which could occur on startup with some very slow computers has been fixed.
• 1028035: Application log files (if generated) are now time-stamped and saved in the %temp% folder.
• 948698, 938158: Auto saved files have been added for most of the MAXSURF Modules. In the event of an unexpected crash, these restore files can be found in the %TEMP% folder:
![Multiframe CONNECT Edition V22 Update 3]()
This feature may me disabled or the Auto-save interval adjusted using the following Registry settings:
TempBackupFile_AutoBackupIntervalSeconds
TempBackupFile_DoAutoBackup
![Multiframe CONNECT Edition V22 Update 3]()
• 1079285: Fixed incorrect Kl/rcalculation in Compressive Capacity check for AISC ASD2010
• 1068670: Afterturningoff patch visibility, patch results are still visible in plot window.Fixed
• 1067218: Set best section for a design member causes a crash. Fixed.
• 1064896: The rendered model now correctly updates when the section type is changed from the dorp-down combo-box.
• 1047721: Random crash for certain models due to model depth sorting. Fixed
• 1040812: A crash which occurred when performing a plate analysis in Multiframe basic has been fixed.
• 1015006: A problem which caused non-uniform,distributed patch loadsto beshown intheincorrect directionhas been fixed.
• 1067218; Set best section for a design member causes a crash. Fixed.
• 228207: A LRFD bug where effective section propertieswere not calculated for no-compact HSS sectionshas been fixed.
• 1050044, 1030356: A crash which could occur on startup with some very slow computers has been fixed.
• 1028035: Application log files (if generated) are now time-stamped and saved in the %temp% folder.
• 948698, 938158: Auto saved files have been added for most of the MAXSURF Modules. In the event of an unexpected crash, these restore files can be found in the %TEMP% folder:
Multiframe CONNECT Edition V22 Update 3
This feature may me disabled or the Auto-save interval adjusted using the following Registry settings:
TempBackupFile_AutoBackupIntervalSeconds
TempBackupFile_DoAutoBackup
Multiframe CONNECT Edition V22 Update 3
• 1079285: Fixed incorrect Kl/rcalculation in Compressive Capacity check for AISC ASD2010
• 1068670: Afterturningoff patch visibility, patch results are still visible in plot window.Fixed
• 1067218: Set best section for a design member causes a crash. Fixed.
• 1064896: The rendered model now correctly updates when the section type is changed from the dorp-down combo-box.
• 1047721: Random crash for certain models due to model depth sorting. Fixed
• 1040812: A crash which occurred when performing a plate analysis in Multiframe basic has been fixed.
• 1015006: A problem which caused non-uniform,distributed patch loadsto beshown intheincorrect directionhas been fixed.
• 1067218; Set best section for a design member causes a crash. Fixed.
• 228207: A LRFD bug where effective section propertieswere not calculated for no-compact HSS sectionshas been fixed.
Multiframe CONNECT Edition V22 Update 3
Multiframe CONNECT Edition V22 Update 3
Multiframe provides linear and non-linear analysis, static and dynamic options and buckling calculations. These analysis options are complemented by a full range of analysis-related modeling tools like master-slave, prescribed displacements, springs, thermal effects, offset members, additional masses and much more. Other modules allow you to draw sectionshapes and install them in the sections library and perform design checks for a range of design codes. Multiframe Automation allows you to prepare design calculations in Excel and link them directly with your Multiframe model. An ever expanding range of design add-ons also allows you to simplify steel code checking and optimization.
Multiframe helps you redefine design excellence for any types of structures. Choose the version that fits your project needs:
Multiframe: Linear analysis of frame and plate structures, non-linear analysis of frames, Section properties calculator, local steel code checks (AS4100, AS4600, NZS3404)
Multiframe Advanced: Mutiframe capabilities plusdynamic modal analysis and time history analysis,International steel design codes(AIJ, ASD, LRFD, AISI, BS5950, EC3).
This video shows how to define sections and material properties
Bentley Systems, Incorporated. is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Product: Multiframe
Version: CONNECT Edition V22 Update 3 (version 22.03.00.121)
Supported Architectures: x64
Website Home Page : www.maxsurf.net
Language: english
System Requirements: PC *
Supported Operating Systems: *
Size: 1.0 Gb
Installation Requirements
Supported Operating Systems
Windows 10 (64-bit): Home, Pro, Enterprise, and Education
Windows 8.1 (64-bit): Standard, Pro, and Enterprise
Windows 8 (64-bit): Standard, Pro, and Enterprise
Note: For Window 8 and 8.1, you must have the Microsoft KB2919355 installed on your machine. Bentley does not support its software running on Microsoft operating systems versions that Microsoft has "retired".
Software Prerequisites
The software prerequisites are included in the Multiframe installer.
Supported i-model publishing engines
Publishing i-models from Multiframe requires Bentley ISM
Microsoft Office
For reporting using Microsoft Word, this must be installed on the system.
Minimum Profile
The minimum recommended workstation profile for running Multiframe CONNECT Edition is:
Processor: Intel or AMD processor 1.0 GHz or greater. MicroStation is not supported on a CPU that does not support SSE2.
Memory: 4 GB minimum, 16 GB recommended. More memory almost always improves performance, particularly when working with larger models.
Hard Disk: 4 GB free disk space (which includes the 2 GB install footprint for a complete installation)
Video: Graphics card which fully supports DirectX 11 and OpenGL with up to date drivers. A stand-alone graphics card with 512 MB of video RAM or higher is recommended.
Screen: A resolution of at least 1024 x 768 or higher.
No Longer Supported or Delivered
Windows 7 support: Whilst MAXSURF software may well continue to function on Windows 7 with SP1, this operating system is no longer officially supported by Bentley Systems. Microsoft support for Windows 7 ended on January 14, 2020.32-bit operating systems are no longer supported.
Supported Operating Systems
Windows 10 (64-bit): Home, Pro, Enterprise, and Education
Windows 8.1 (64-bit): Standard, Pro, and Enterprise
Windows 8 (64-bit): Standard, Pro, and Enterprise
Note: For Window 8 and 8.1, you must have the Microsoft KB2919355 installed on your machine. Bentley does not support its software running on Microsoft operating systems versions that Microsoft has "retired".
Software Prerequisites
The software prerequisites are included in the Multiframe installer.
Supported i-model publishing engines
Publishing i-models from Multiframe requires Bentley ISM
Microsoft Office
For reporting using Microsoft Word, this must be installed on the system.
Minimum Profile
The minimum recommended workstation profile for running Multiframe CONNECT Edition is:
Processor: Intel or AMD processor 1.0 GHz or greater. MicroStation is not supported on a CPU that does not support SSE2.
Memory: 4 GB minimum, 16 GB recommended. More memory almost always improves performance, particularly when working with larger models.
Hard Disk: 4 GB free disk space (which includes the 2 GB install footprint for a complete installation)
Video: Graphics card which fully supports DirectX 11 and OpenGL with up to date drivers. A stand-alone graphics card with 512 MB of video RAM or higher is recommended.
Screen: A resolution of at least 1024 x 768 or higher.
No Longer Supported or Delivered
Windows 7 support: Whilst MAXSURF software may well continue to function on Windows 7 with SP1, this operating system is no longer officially supported by Bentley Systems. Microsoft support for Windows 7 ended on January 14, 2020.32-bit operating systems are no longer supported.
