Keysight Advanced Design System (ADS) 2022 Update 0.1

Keysight Technologies, Inc., a leading technology company that delivers advanced design and validation solutions to help accelerate innovation to connect and secure the world, announced a comprehensive workflow solution - PathWave Advanced Design System (ADS) 2022 - that reduces design time and de-risks product development for Double Data Rate 5 (DDR5), Low-Power Double Data Rate (LPDDR5) and Graphics Double Data Rate 6 (GDDR6) memory systems.

From cloud computing to autonomous vehicles, the demand for faster memory interfaces is accelerating. A disruptive technology feature of fast interfaces such as DDR5, LPDDR5 and GDDR6 is equalization on the memory chip’s receivers, which recovers signals degraded by their path through the printed circuit board (PCB). Hardware engineers need to minimize the risk of signal integrity issues in memory bus designs, which requires the ability to predict the signal quality after equalization, prototype the design and test for performance.

Keysight’s PathWave ADS 2022, a design and test workflow for next-generation memory, enables hardware engineers to meet time-to-market requirements and deliver a high-performance, reliable end-product. The Memory Designer in PathWave ADS 2022, addresses the following design challenges:

- Model the transmitter and receiver behavior accurately by generating advanced simulation models of both DDR transmitters and receivers, with flexible equalization and external clock inputs.
- Optimize equalization settings to predict design margins with an advanced simulator that uses adaptive equalization to find the optimal settings for the best signal integrity of the data link.
- Quantify margin to the eye-mask by predicting eye closure down to standard-specific Bit-Error-Rates, and report remaining margin to the eye-mask.
- Find failing conditions with design exploration by generating a batch simulation list to sweep through all possible design parameters and report passing/failing configurations as spreadsheet data.
- Confidence in design sign-off, from design through to test by performing an automated compliance report on simulated signal waveforms and utilizing consistent measurement science to identify issues early and trial potential fixes efficiently.

ADS 2022 Update 0.1 Release Notes - Release: August 31, 2021
ADS 2022 Update 0.1 (minor update release) is a cumulative minor update release installed on ADS 2022 (base release). You can upgrade your existing ADS installation (ADS 2022) to ADS 2022 Update 0.1 without uninstalling any previous minor updates (if available any).

Enhancements
- ADS 2022 Update 0.1 includes enhancements in Circuit Simulation and HSD
Circuit Simulation
Added support for doublequotes nested into singlequotes in hspice.
HSD
- Allow users to change the plot title in s-parameters window.
- Higher default value, 40GHz, for the phase interpolator's parasitic cutoff frequency with single ended PAM4.
- When you double-click the plot title in the S-Parameter toolkit, it allows you to edit the title. Also, you can reset to the default name using the "Set to Default" button.



Advanced Design System (ADS) is the world’s leading electronic design automation software for RF, microwave, and high-speed digital applications. ADS pioneers the most innovative and powerful integrated circuit-3DEM-thermal simulation technologies used by leading companies in the wireless, high-speed networking, defense-aerospace, automotive and alternative energy industries. For 5G, IoT, multi-gigabit data link, radar, satellite and high-speed switched mode power supply designs, ADS provides an integrated simulation and verification environment to design high-performance hardware compliant with the latest wireless, high speed digital and military standards.

PathWave Advanced Design System (ADS) 2022 simulation software reduces design time and de-risks product development for DDR5, LPDDR5 and GDDR6 memory systems.

What’s New in ADS 2022?


This playlist provides a list of videos showing new or updated features/capabilities in PathWave Advanced Design System (ADS) 2022.
Keysight Technologies Inc. is the world's leading electronic measurement company, transforming today's measurement experience through innovations in wireless, modular, and software solutions. With its HP and Agilent legacy, Keysight delivers solutions in wireless communications, aerospace and defense and semiconductor markets with world-class platforms, software and consistent measurement science. The company's nearly 10,500 employees serve customers in more than 100 countries.

Product: Keysight Advanced Design System (ADS)
Version: 2022 Update 0.1
Supported Architectures: x64
Website Home Page : www.keysight.com
Languages Supported: english
System Requirements: PC *
Size: 2.9 Gb
