InnovMetric PolyWorks Metrology Suite 2020 IR2

InnovMetric, the global leader in smart 3D metrology software solutions, has introduced PolyWorks MS 2020, the latest release of its 3D dimensional analysis and quality control solution. New release offers multipiece editing capabilities that accelerate the preparation of robust inspection projects and facilitate data analysis. This new major release also extends the universality of its digitizing hub by adding support for new measurement instruments, and increases CNC CMM productivity by accelerating the execution of measurement sequences.

Boost the quality of project setup and analysis by leveraging multiple scanned models

PolyWorks|Inspector now allows users to modify and add data alignments, measurement objects, and inspection reports for multiple measured pieces at once.

The new capability will allow PolyWorks users to more easily prepare robust inspection projects that handle all pieces. When a user builds an initial project and starts measuring pieces, he may encounter a problematic piece for which the object extraction parameters do not work properly. The new multipiece editing technology allows him to fine-tune the object’s extraction and fitting parameters until satisfactory results are obtained, and then apply these changes to all previously scanned pieces in one operation, to ensure that the new parameters do not negatively impact the other pieces.

Multipiece editing is also a very powerful tool for quickly investigating a production failure by analyzing previously fabricated pieces. When a failing piece is detected, new measurement objects and reports are generally required to get additional information. PolyWorks 2020 now allows users to add these new objects and reports to a subset of selected pieces in a single operation, to analyze object measurement results, trend charts, and statistics on these pieces, with the goal of better understanding the conditions that led to the failure.

Benefit from the extended universality of the portable metrology solution

PolyWorks MS 2020 enhances its portable metrology workflows and adds interfaces for new instruments, expanding the limits of the PolyWorks|Inspector platform:

- Construct planes and lines from already measured objects and access the complete GD&T toolbox and fitting statistics;
- Trigger the use of Creaform laser scanners within the Play Inspection tool;
- Enjoy high-performance measurement methods that leverage the capabilities of the Leica ATS600 tracker; and,
- Connect to a MicroRidge MobileCollect wireless system and bring measurements from handheld gauges into inspection projects.

Increase CNC CMM productivity

More and more CNC CMM users are adopting PolyWorks MS as they discover its outstanding ease of use and performance. Version 2020 enhances and broadens its CNC CMM solution to help users increase their productivity in their ultracompetitive markets by:

- Accelerating the execution of CNC CMM sequences while probing in fly mode (up to 50% faster) and laser scanning;
- Ensuring that CMM positions are reachable by the machine to avoid invalid moves when defining a sequence offline, or assist when porting a sequence to a CMM with a different measurement volume; and,
- Offering the control of Hexagon and Zeiss CMM-based laser scanners through I++.

Accelerate inspections tasks

PolyWorks MS 2020 offers enhanced tools and new technologies that eliminate the guesswork and help users work faster. Now, they can:

- Optimize and augment their GD&T toolkit, thanks to improved algorithms that accelerate 2-point distance calculations and produce more accurate and repeatable results, and the support of a new Combined Zone modifier;
- Quickly learn and master interactives modes, thanks to new user-friendly contextual toolbars and improved guidance;
- Easily share their customized toolbars and their macros with colleagues and partners;
- Link multipiece inspection projects to their Excel spreadsheets with PolyWorks|ReportLoop; and,
- Integrate mixed reality display from PolyWorks|AR into their guided measurement workflows.

See Release Notes for contains enhancements and fixed issues in the Intermediate Release 2

PolyWorks is the leading software solution for high-end point cloud inspection and reverse engineering applications. Defining the cutting edge of 3D metrology, the software suite maximizes productivity, quality, and profitability when integrating 3D measurement technologies into an industrial manufacturing process.

From part and tool design and prototyping down to final inspection of assembled products, PolyWorks software offers advanced solutions to cover the complete product development cycle. Interfacing directly with major brands and technologies of single-point and point cloud 3D measurement devices through plug-in extension modules, this universal platform also supports a wide array of native point cloud and polygonal model file formats. With its fully customizable user interface and powerful, user-friendly macro programming language, PolyWorks offers the most adaptable software solution on the 3D metrology market. This flexibility allows our customers to successfully develop and deploy automatic inspection processes or guided operator-driven workflows for effective shop floor operations.

Webinar: Inspect Parts by Scanning Without Using CAD Models


InnovMetric Software Inc. is the leading provider of universal 3D metrology software solutions. The world’s largest industrial manufacturing organizations trust our software solutions and technical services to maximize the benefits of 3D measurement technologies for their engineering applications.

Product: InnovMetric PolyWorks
Version: 2020 IR2 Build 2948
Supported Architectures: x64
Website Home Page : www.innovmetric.com
Language: english
System Requirements: PC *
Supported Operating Systems: *
Size: 1.6 Gb
