InnovMetric PolyWorks Metrology Suite 2018 IR1

InnovMetric Software Inc., has released update the 2018 release of PolyWorks. This latest major release of the company’s universal 3D metrology software platform delivers universal inspection projects playable on any 3D measurement device, an enhanced alignment toolbox, smart collision avoidance for CNC CMMs, even more robust measurement sequences for CNC CMMs, and enhanced usability and performance that promote valuable gains in user productivity.

Intermediate Release Notes 1:

InnovMetric Software offers intermediate releases of the PolyWorks Metrology Suite on a near-monthly basis. These intermediate releases contain new tools, improvements to existing tools, and fixed issues. These changes and new tools are documented in the Intermediate Release Notes. For the changes and new tools included in the latest major release of the PolyWorks Metrology Suite, see the WhatisNewInPolyWorks.pdf file.


About InnovMetric PolyWorks 2018. QUEBEC, QC, CANADA, April 4, 2018 – InnovMetric Software Inc., the leading provider of universal 3D metrology software solutions, has launched the 2018 release of PolyWorks at the annual PolyWorks Conference USA event. This latest major release of the company’s universal 3D metrology software platform delivers universal inspection projects playable on any 3D measurement device, an enhanced alignment toolbox, smart collision avoidance for CNC CMMs, even more robust measurement sequences for CNC CMMs, and enhanced usability and performance that promote valuable gains in user productivity.

Inspection projects DIRECTLY PLAYABLE with ALL 3D measurement devices

Since 2016, PolyWorks universal inspection projects are reusable with any 3D measurement device by adapting their object measurement methods and measurement sequences using automatic conversion tools. PolyWorks 2018 empowers users to create and deliver shop-floor-ready inspection projects that are directly playable with any 3D measurement devices. With PolyWorks 2018, users can maximize the use of their 3D metrology hardware and minimize the risk of operator errors by creating and embedding multiple piece measurement templates within a single inspection project!

With piece measurement templates, users can preconfigure an inspection project to:
- Perform multiple piece measurements with CNC CMMs and portable scanning arms
- Execute measurement sequences on bridge CMMs and horizontal arms
- Set up for different laser tracker brands and models
- Handle multiple CAD model versions and revisions
- Manage multiple versions of an inspection routine

Universal inspection projects offer users total flexibility for the overall work organization of their 3D metrology processes.

Smart collision avoidance for CNC CMMs

PolyWorks 2018 adds new measurement sequence fixers to the powerful real-time collision analysis technology. These tools allow inserting automatically computed Go to Position locations that modify the CMM measurement path in an optimal way as to prevent detected potential collisions.

Enhanced alignment toolbox

PolyWorks 2018 reference target and datum target alignment techniques are more powerful and more complete. Users can:
- Balance part deviations using the integrated iterative alignment with reference targets bound to constructed features, which is useful when aligning symmetrical parts and balancing blade edges.
- Simulate rectangular and circular fixture locating pads using the new datum target area.

Robust measurement sequences for CNC CMMs

PolyWorks 2018 offers intelligent solutions for measuring deformed, incorrectly aligned, or deviated parts without operator intervention:
- Search hole – Triggers a spiral search when a hole is not located at its nominal position to estimate the actual hole location, and restarts hole measurement from the estimated location.
- Locate hole center – Measures 3 points to estimate the actual hole location, translates the measurement zone to the center of the actual hole, and launches hole measurement.
- Measure relative to other objects – Adjusts the position of the measurement zone based on the deviations of objects that are already measured.

Enhanced usability and performance

The improved discoverability, ease of use, and performance of tools in PolyWorks 2018 promote valuable gains in user productivity:
- Simplified icons assure quick recognition, while retaining the original icon concepts
- Colors are used to focus attention and better communicate results
- Intuitive annotation positioning and editing tools directly in the 3D Scene
- Single-click geometry transfer between PolyWorks|Inspector and PolyWorks|Modeler

About InnovMetric Software Inc. Founded in 1994 and headquartered in Quebec, QC, Canada, with subsidiaries worldwide, InnovMetric Software Inc. is the leading provider of universal 3D metrology software solutions. The world’s largest industrial manufacturing organizations (Toyota, GM, Volkswagen, Honda, BMW, Daimler, Ford, Rolls-Royce, Pratt & Whitney, Boeing, Embraer, Bombardier, Apple, and many more) trust InnovMetric’s PolyWorks software solutions and associated technical services to maximize the benefits of 3D measurement technologies for their engineering and manufacturing applications.

Product: InnovMetric PolyWorks
Version: 2018 IR1 Build 3553
Supported Architectures: 32bit / 64bit
Website Home Page : www.innovmetric.com
Language: english
System Requirements: PC
Supported Operating Systems: Windows 7even or newer
Size: 3.2 Gb
