InnovMetric PolyWorks 2016 IR2.1
InnovMetric PolyWorks 2016 IR2.1 | 2.3 Gb
InnovMetric Software Inc., the leading provider of universal 3D metrology software solutions, has released update of PolyWorks 2016, the latest release of the company’s universal 3D metrology software platform. PolyWorks 2016 fully supports probing and laser scanning on stationary CNC CMMs, and delivers a truly universal 3D metrology workflow that will allow users to operate any type of portable metrology and CNC CMM measurement device within a common framework, from a single software module, and using similar tools and methods.
With PolyWorks 2016, portable metrology and CNC CMM operators are now able to:
- Define a measurement plan without being physically connected to a specific measurement device;
- Specify geometry controls on measurement objects and prepare inspection reports;
- Connect to a non-contact or a contact-based portable metrology device, or to a CNC CMM controller (from Hexagon, Mitutoyo, Nikon, Pantec, Wenzel, and I++ servers), to play the measurement sequence;
- Review measured object geometry controls and reports, or multipiece inspection results through the built-in SPC functionality.
Operating portable metrology and CNC CMM devices within a common framework is now possible with the introduction of two new major components in PolyWorks 2016: the measurement sequence editor and the offline simulation.
InnovMetric PolyWorks 2016 IR2.1
Measurement sequence editor
Since 2012, PolyWorks has offered the powerful Play Inspection tool that automatically generates a step-by-step guided measurement sequence to capture 3D datasets of a new piece using portable metrology devices. PolyWorks 2016 expands the capabilities of the Play Inspection technology by allowing the customization of its automatically generated sequence. Using the new sequence editor, users can now:
- Configure the order of measurement operations;
- Control device position moves;
- Trigger CMM-specific operations, such as moving the probe head to a specific location or changing the orientation of a measurement tool;
- Easily add guidance messages and images;
- Create conditional blocks of operations;
- Insert macro scripts, opening up unlimited process customization possibilities.
InnovMetric PolyWorks 2016 IR2.1
Offline simulation
PolyWorks 2016 also delivers a new easy-to-use offline simulation functionality that automatically generates simulated point cloud data and probed points from a CAD model of the measured part, while going through a simulated measurement workflow. Offline simulation allows users to quickly create simulated measured object components, Data alignments, Data color maps, geometry control tables, 3D scene snapshots, and inspection reports before the real measurement task, without needing access to a measurement device. The PolyWorks 2016 offline simulation also fully supports CNC CMMs, allowing users to control the probing and laser scanning tool orientations and trajectories on a virtual device.
Universal inspection projects
Thanks to the universal 3D metrology architecture of PolyWorks 2016, only minimal changes will need to be made to a PolyWorks inspection project so that it can be used with multiple hardware platforms to optimize object measurement methodologies and adapt them to different measurement principles. As a result, PolyWorks 2016 opens a new era for universal inspection projects and device interoperability, ensuring total flexibility for customers to select the appropriate measurement devices for their needs and maximize the return on their 3D metrology investments.
InnovMetric PolyWorks 2016 IR2.1
About InnovMetric Software
Founded in 1994 and headquartered in Quebec, QC, Canada, with subsidiaries worldwide, InnovMetric Software Inc. is the leading provider of universal 3D metrology software solutions. The world’s largest industrial manufacturing organizations (Toyota, GM, Volkswagen, Honda, BMW, Daimler, Ford, Rolls-Royce, Pratt & Whitney, Boeing, Embraer, Bombardier, Apple, and many more) trust InnovMetric’s PolyWorks® software solutions and associated technical services to maximize the benefits of 3D measurement technologies for their engineering and manufacturing applications.
Name: InnovMetric PolyWorks
Version: 2016 IR2.1 Build 3909
Home: www.innovmetric.com
Interface: english
OS: Windows XP / Vista / 7even / 8 / 8.1
Size: 2.3 Gb
InnovMetric PolyWorks 2016 IR2.1
visit my blog
All parts interchanged. Added by 3% of the overall size of the archive of information for the restoration and the volume for the restoration
No mirrors please
