DS CADAM Drafting V5-6R2018 SP2

Dassault Systemes has released an updated (SP2) version of CADAM Drafting Version 5-6 Release 2018, is the most advanced yet easy-to-use layout and drafting system available for brings the intuitive and productive CADAM 2D design and drafting paradigm to CATIA solutions.

What's new in CADAM Drafting Version 5-6 Release 2018 SP2:

The following changes have been made to the CADAM Drafting product since the Version 5-6 Release 2017 base release.

- TIFF Converter (added in SP2)
A new program, ccdtiffconverter.exe, has been added to the bin folder. This routine can be used to convert color raster images to monochrome TIFF images that can then be imported into CADAM Drafting. Run the program and select Help for instructions on using the program.
- New IUE Function - U1QDMA (added in SP2)
A new IUE function, U1QDMA, has been added. This function allows you to query the elements associated to an associative dimension.
- New IUE Samples (added in SP2)
Two new IUE sample programs - one for Fortran and one for C - have been added under the IUE\TOOLS folder.
- New IUE Programs (added in SP2)
Five new IUE programs have been added. They are all batch programs and have been added under the IUE\BIN folder. The programs are dupgeometry.iue for removing duplicate geometry, modelmerge.iue for merging models, overlaymerge.iue for merging overlay families, removeview99.iue for removing view 99 from drawings and unuseddetail.iue for removing unused details from models. These programs are provided as-is. If user modifications are required, the source for these programs has been provided in the IUE\TOOLS\Source folder.

Problems Fixed in CADAM Drafting Version 5-6 Release 2018 SP2:

BR10000244186 - Dialog: Multi-model environment crashes when 3 or more models are opened at the same time.
CCD00001 - Dialog: Preselect highlight does not always switch when moving from element to element.
CCD00002 - Dialog: Do not allow pan and zoom events to cross out of the window they were initiated in.
CCD00003 - EFT: Don't put end condition blocks in the frozen no-sho layer.
CCD00004 - File: A drawing with an unusually large number of bad elements crashes when opened.


About CADAM Drafting. The product CATIA - CADAM Interface 1 (CC1) provides the user with an integrated capability to share 2D drafting information between CATIA CADAM Drafting (CCD) and V5 Drafting products.

This integrated capability provides existing CCD users with the flexibility to easily integrate the V5 CATIA product portfolio into their environment, while maintaining their current practices and procedures based on their CCD product use.

Product Highlights:

- Direct access to CATIA-CADAM Drafting drawings from the CATIA V5 drafting products
- Reduces transfer a cleanup time
- Automatic conversion into native V5 drawings
- Reuse of CATIA-CADAM Drafting data in CATIA for continuing the design in 2D or 3D

About Dassault Systemes.As a world leader in 3D and Product Lifecycle Management (PLM) solutions, Dassault Systemes brings value to more than 130,000 customers in 80 countries. A pioneer in the 3D software market since 1981, Dassault Systemes applications provide a 3D vision of the entire lifecycle of products from conception to maintenance to recycling. The Dassault Systemes portfolio consists of CATIA for designing the virtual product - SolidWorks for 3D mechanical design - DELMIA for virtual production - SIMULIA for virtual testing - ENOVIA for global collaborative lifecycle management, EXALEAD for search-based applications and 3DVIA for online 3D lifelike experiences.

Product: DS CADAM Drafting
Version: V5-6R2018 SP2
Supported Architectures: x86
Website Home Page : www.cadam.com
Language: multilanguage
System Requirements: PC
Supported Operating Systems: Windows 7even or newer
Size: 155.1 mb
