Creo Parametric PDX 7.0 M010

Tooling development for progressive dies is best approached with a purpose-built solution. With PTC Creo Progressive Die Extension software, easy-to-use wizards guide the user through automatic strip layout definition, cut stamp creation, and placement/modification of die components. Documentation, clearance cuts, and drilled holes are created automatically, enabling die designers to avoid manual, error-prone tasks.

- Process-oriented workflow automates progressive die design and detailing, enabling quicker time to production
- Includes large library of die components and fasteners for faster detailed design
- Speeds unbending and identification of features for staging
- Increases design flexibility, allowing new stages to be added even after the die is created
- Increases efficiency through automation of repetitive tasks, such as creating clearance cuts

What's new in this release

PTC is pleased to present Creo Progressive Die Extension (PDX), a renaming of Pro/ENGINEER Progressive Die Extension and Creo Elements/Pro Progressive Die Extension. Creo provides a path towards PTC’s new design software.

PDX 7.0 is supported for Pro/ENGINEER Wildfire 4.0 and later Creo Parametric releases. Datecodes, sometimes known as build dates, for the two products must be compatible for the proper functioning of PDX.

PDX 7.0 is interoperable with the following Product Data Management (PDM) solutions from PTC: Pro/INTRALINK 8.0 and later, Windchill PDMLink 8.0 and later, and Windchill ProductPoint 1.1 and later. Starting with this release, the interoperability of PDX with other PTC products matches that of Creo Elements/Pro and Creo. All PTC products with datecodes compatible with Pro/ENGINEER Wildfire 4.0, Creo Elements/Pro 5.0, or Creo 1.0 run with PDX.

About PTC

PTC is all about helping discrete manufacturers succeed by meeting their globalization, time-to-market, and operational efficiency objectives in product development. As one of the world's largest and fastest-growing software companies, we deliver a complete portfolio of integral Product Lifecycle Management solutions to over 25,000 customers in the Industrial, High Tech, Aerospace & Defense, Automotive, Consumer, and Medical Device industries.

Our people and technology enable teams to collaborate across departments—and across continents—helping you create innovative products that meet your customer needs and comply with industry regulations. In addition to best-in-class solutions, we also deliver expert training, software support, and world-class services both through PTC Global Services and a vast partner ecosystem–so you get the maximum value and ROI from your PTC software. Whether you’re a small or mid-sized business looking to migrate from 2D to 3D, or a global enterprise managing multiple product lifecycles, you’ll find exactly what you need with PTC – the Product Development Company.


visit my blog

Name: PTC Creo Parametric Progressive Die Extension
Version: 7.0 M010
Home: www.ptc.com
Interface: multilanguage
OS: Windows XP / Vista / Seven
Size: 220.0 mb
