Cadmai v3.11

CADMAI is a relational 2D and 3D CAD system , which can be integrated in 3rd party applications or in a SOA environment.

Features:

Basic Features

* Completely parametric and relational
* Integrated script API which serves as a modeling language
* Can be steered by external applications
* Can be hosted in external applications
* Embedded formula interpreter
* Supports a hierarchical assembly structure
* User defined animations
* User defined entity attributes and methods
* API for embedding CADMAI in external solutions
* Base geometry API for technical applications

Non geometric entities

* User defined dialogs
* User defined objects
* User defined variables
* Attributes
* Tables and row cursors incl. ODBC Database connections
* Layers
* Programming structures (loop/ifthen) which can be integrated in the model

2D entities

* Points (15 creation methods)
* Lines (11 creation methods)
* Arcs (20 creation methods)
* Curves
* Views and sections from solid data
* Hatches/area fill
* Transformations
* Symbols
* Text
* Labels
* Dimensioning

3D entities

* Coordinate systems
* Solid creation (16 creation methods)
* Solid modification (23 methods)
* Polygon based 3D representations (Wavefront/3DS/…)
* Components
* FEM Meshes

Import/Export

* Bill of material (table format)
* DXF, IGES, STEP, VRML, STL, XCAF, PARASOLID/ACIS/3D-DXF on request
* OBJ, 3DS, ASC, X, OBT, IOB, DAT, LWO, C, UDO, RAW, RWX, SCE
* BMP, PNG, JPG, TIFF
* AVI
* User defined export formats

API (native and DotNet)

* Windows API
enables the user to embed CADMAI Windows in applications. CADMAI herby provides special Window classes which can be used similar to the Common Controls
* Object API
serves as an independent geometric library which can be used outside of CADMAI.
This library includes the following objects:
Points, Lines, Arcs, Curves, Hatches, Matrices, Coordinate systems, Views, Solids,
Greps, Dimensions, Symbols, Texts, Tables, Cursors, Layers, Attributes, Variables, Dialogs
* Batch API
enables the usage of CADMAI batch processes and the control of loaded CADMAI models.
* Connect API
enables the connection to CADMAI batch process at the same or a remote computer and the remote control of the process.
