Cadence Design Systems, Inc. , the leader in global electronic design innovation, has unveiled a new of improvements in hotfix 016 to the Cadence SPB Allegro and OrCAD 17.40 families of products aimed at boosting performance and productivity through improvements features and big fixed issues.
=======================================
CCRID Product ProductLevel2 Title
===================================================
2436435 ADW PART_MANAGER Alternate symbols defined in Part developer not transferring in System Capture netlist.
2348286 ALLEGRO_EDITOR 3D_CANVAS PCB Editor crashes or stops responding when opening DRA file in 3D canvas.
2424373 ALLEGRO_EDITOR 3D_CANVAS 3D Mapper not working correctly: Model and footprint not in sync
2424620 ALLEGRO_EDITOR 3D_CANVAS Bend operation is disabled and results in error message
2428800 ALLEGRO_EDITOR 3D_CANVAS 3D Mapper is not working as expected: Appearance of footprint and model not in sync and loss of mapping data
2428911 ALLEGRO_EDITOR 3D_CANVAS 3D Mapper is not retaining mapping data
2439598 ALLEGRO_EDITOR 3D_CANVAS 3D Mapper is not retaining STEP mapping position
2440504 ALLEGRO_EDITOR 3D_CANVAS 3D Mapper is not remembering the mapping data.
2440621 ALLEGRO_EDITOR 3D_CANVAS 3D Mapper is not retaining the position of STEP models after Auto Mapping the models
2443210 ALLEGRO_EDITOR IPC Allegro MNF Option - DFM Checker - Silkscreen Checks to not show DRC's in Results tab section. Test Case Provided.
2434753 ALLEGRO_EDITOR UI_FORMS Cannot set layers in IFF layer map GUI
2438790 ALLEGRO_EDITOR UI_GENERAL Allegro PCB Editor crashes when started with Dark theme and scriptmode is set to +i (invisible)
2428226 APD DEGASSING Advanced deferred degassing stops responding when running script
2426589 CAPTURE DEMO Discrepancies with OrCAD Capture demo design: Same design fails in some cases and passes in others
2355351 CAPTURE GENERAL Release 17.4-2019, Capture Sub-block Navigation: Closing second block gets focus on the top most block
2433965 CAPTURE OTHER Not able to change product license
2435044 CAPTURE OTHER License call fail with error (LMF-02004) and unable to change license in specific condition
2441130 CAPTURE OTHER No license choice for Capture in release 17.4-2019, HotFix 014 when default license is in use
2441595 CONCEPT_HDL CORE Starting non-graphical version using 'nconcepthdl' results in exit with error regarding missing project name
2309197 CONSTRAINT_MGR ACC ACC: Error message (SPACC-53) regarding min value exceeding max value on importing rule files
2439515 ORBITIO OTHER Merge Updated DEF changes the DIE size.
2445932 PCB_LIBRARIAN SYM_CREATOR_C Block symbol editing: Cannot edit or delete note added to a symbol
2359797 PSPICE TI_OUT_OF_CON Capture crashes on editing simulation setting if design name has accented characters
2451668 PULSE R2PLM-WC Variant BOM not getting published correctly
2438035 SIP_LAYOUT REPORTS Incorrect tolerance numbers in Cross-Section Report
2435952 SIP_LAYOUT STREAM_IF Stream out results in crash if a variable is set on a specific database in release 17.2-2016
2427990 SYSTEM_CAPTURE REPORTS System Capture Single Node Net Reports show an individual NC signal used inside block
