Cadence OrCAD X Design Platform 2024.1 HF006 (24.10.006)

3161262 ALLEGROX 3D_CANVAS Allegro X layout editor quits unexpectedly when 3DX canvas is launched
3174575 ALLEGROX 3D_CANVAS 3DX Canvas quits unexpectedly
3155781 ALLEGROX ASR_ROUTER Advanced Substrate Router Delay Tune does not tune
3157016 ALLEGROX ASR_ROUTER Advanced Substrate Router quality of routing needs improvement; leaves many 90 degree corners and LL DRCs
3158027 ALLEGROX ASR_ROUTER Add user name to the ASR log file
3066156 ALLEGROX DATABASE 'Delete unused subclass' in database check causes a change in films order
3142585 ALLEGROX DATABASE axlDeleteByLayer(layer) corrupts database
3144343 ALLEGROX DATABASE Tool quits unexpectedly when exporting netlist using SKILL
3151504 ALLEGROX DFA Spelling mistake in the pop-up dialog box for DFA Constraint Spreadsheet
3157825 ALLEGROX DFA DFA Table import as part of a release 17.2 to 24.1 uprev does not show all the DFA bubbles.
3161420 ALLEGROX DRC_CONSTR Conn Type Slot Vias requires percentage value in Constraint Manager to suppress DRCs when a slight misalignment exists
2731247 ALLEGROX EDIT_ETCH Phase Control Height Value - Interactive Command Updates
3134294 ALLEGROX FLOORPLANNER System Capture missing an option to select APD as a product from an associated mdd file
3149242 ALLEGROX IN_DESIGN_ANA Topology Extraction Workflow displays error and quits unexpectedly after attempting topology extraction for a given net
3105576 ALLEGROX NC Backdrilled (bottom-up) buried via has soldermask opening on the bottom where it should not be.
3109064 ALLEGROX NC Getting Error SPMHMF-20 in Command window even if Enable is selected in Backdrilling setup.
3150862 ALLEGROX PULSE Open Version and cancel request for copy stills updates active version marker
3150875 ALLEGROX PULSE Lock Icon consistency between System Capture and PCB Editor
2963562 ALLEGROX REPORTS Migrate APD+ metal density scan utility into Allegro PCB Editor
2420720 ALLEGROX SHAPE Minimum aperture for gap width calculation method for corners
3180170 ALLEGROX SHAPE Crash when DRC check is performed caused by shape with no outline that gets created during dynamic voiding
3159691 ALLEGROX UI_GENERAL Customer cannot load a custom workflow .xml file in PCB Editor of release 24.1 hotfix 004
3168499 ALLEGROX UI_GENERAL Design Workflow panel not loading in release 24.1 due to XML syntax errors
3170669 ALLEGROX UI_GENERAL NY crash when their SKILL code errors out during exit callback and their standard error handler tries to open a dialog
3088754 ALLEGROX WIREBOND Bond wire connection grater than 100
2937545 APD 3D_CANVAS enhancement request to add 3DX in right click options when selecting nets and vias to view backdrills
3024813 APD 3D_CANVAS Ability to render selected objects in 2D canvas when 3Dx is invoked
3143051 APD 3D_CANVAS Cross probe single or group of nets in 3DX behavior is different than 3D
3152483 APD 3D_CANVAS Ability to selectively view objects in 3DX (RMB-> 3DX) based on selection in 2D canvas
3183494 APD 3D_CANVAS Cross-probing of nets is not possible in 3DX and requires multiple clicks to view net in 3DX which is different from 3D.
3155779 APD DATABASE Allegro X Advanced Package Designer quits unexpectedly when Place - Via array command is run
3144822 APD DEGASSING Cannot degas LAYER_1 in APD 24.1
3163511 APD DEGASSING Unable to generate multiple patterns degassing holes (with degassing slot).
3118980 APD DRC_CONSTRAIN APD DRC Browser takes excessive amount of time to open
3134326 APD DRC_CONSTRAIN Max Via Dielectric Span does not work with nested constraint regions
3173029 APD IN_DESIGN_ANA Aurora ICP performance issues: Need to wait 1 minute to populate signal text on a form for demos
3066316 APD ORBITIO_IF Delete routing connected to pins when logic is changed during ISP ECO
3132107 APD ORBITIO_IF orbit2allegro/allegro2orbit: support CTE compensation translator for Integrity 3D-IC platform
3154341 APD OTHER Si Layout Option/DRC/Import External DRCs error
3193915 APD OTHER Running Ravel script crashes APD (24.1 S005)
3195319 APD OTHER APD crash on a SKILL with axlPolyExpand() on 24.1 S005 but not on 24.1 S004
3173229 APD PLACEMENT APD performance enhancement of the via array delete
3144674 APD SHAPE Design has shapes that DBdoctor cannot fix
3127036 APD WLP PVS submission form unable to come to active state from the load tab.
3144494 APD WLP Import Techfile: Translate via-to-via spacing into QBR HDI Vias spacing
3145730 APD WLP Allegro X Advanced Package Designer not transferring large streamed out database to Linux
3151268 APD WLP Package integrity checker: Route Keepout Region false violations on vias/pins
3151577 APD WLP Rule selector tab should not collapse after a rule is selected.
3152233 APD WLP Import Techfile: Translate degassing void to adjacent layer void clearance
3154840 APD WLP Auto-fixer to remove overlapped vias
3160704 APD WLP Import Techfile: Incorrect padstack drill figure type when reimoprting techfile
3138143 CAPTURE CROSSREF Crossprobing retains previous nets in the XProbe Results window, even if they are deselected from the layout.
3161837 CAPTURE FILEMANAGER Cannot access CLOUD File Manager
3163419 CAPTURE WORKSPACECONF BREAK 'New Workspace' option accessible with POX050/POX100 license
3154211 INSTALLATION BASE 24.1 base installation of the InstallDiagnose application references release 23.1 instead of 24.1
3151464 LIVEDOC EXPORT Incorrect objects on SPBT layer in PDF export from LiveDoc
2871906 PSPICE AA_MC Unable to display result of Montecarlo advance analysis done using script pspAATempSweepMc.tcl
3162765 PSPICE SIMULATOR Using ENABLE_PARALLEL_TEMPSWEEP does not honor negative temperature value
3169029 PULSE ADHOC Opening board from System Capture gives Error SMPHAI-161
3159168 PULSE UNIFIED_SEARC Designdatamart fails to start in release 24.1 hotfix 002
2766085 PULSE_SERVER MISCELLANEOUS 'Open Projects' window in Project Dashboard takes a long time to load the list of projects
2939206 PULSE_SERVER MISCELLANEOUS Web Dashboard takes 13 seconds to load using System Capture with Pulse in release 22.1 hotfix 008
2940382 PULSE_SERVER MISCELLANEOUS Project dashboard performance in release 22.1 hotfix 008: Long time for data to load in 'Open from Pulse' window
3159147 PULSE_SERVER MISCELLANEOUS Open Project from System Capture returns incomplete list
3148511 SYSTEM_CAPTURE CONSTRAINT_MA Wires and text miss alignment in the EDIF 300 Viewer
3158803 SYSTEM_CAPTURE COPY_PROJECT 'Copy Project As' option does not behave correctly
3145871 SYSTEM_CAPTURE DBDOCTOR Cannot clear net from project data
3147658 SYSTEM_CAPTURE DBDOCTOR /PGND/ Manul sync warning
3091801 SYSTEM_CAPTURE DELETE Team Design CPBF-11 error
3141823 SYSTEM_CAPTURE DELETE Internal error when updating schematic
3144744 SYSTEM_CAPTURE DELETE User is experiencing difficulties with version control: error CPBF-11
3148528 SYSTEM_CAPTURE EXPORT_PCB exportNetList tcl command always return 0 whether netlist run successfully or fails.
3162315 SYSTEM_CAPTURE FORMAT_OBJECT Edit - Preferences - Wiring/Ports - Enable Wire Segment Styling on: Schematic symbol outline color cannot be changed
3186669 SYSTEM_CAPTURE FORMAT_OBJECT Break in functionality, cannot Edit Drawing Objects
3146433 SYSTEM_CAPTURE IMPORT_BLOCK Some part properties are missing in the migrated System Capture design.
3072696 SYSTEM_CAPTURE IMPORT_DEHDL_ Import DE HDL design not working
3143062 SYSTEM_CAPTURE IMPORT_DEHDL_ Grid settings get overridden while importing DE-HDL sheets despite being locked at site level
3143905 SYSTEM_CAPTURE IMPORT_DEHDL_ System Capture adds an additional property when an existing DE-HDL design is opened
3144643 SYSTEM_CAPTURE IMPORT_DEHDL_ DE-HDL sheet with symbols at finer grid gets imported into System Capture with higher grid setting causing issue
3145960 SYSTEM_CAPTURE IMPORT_DEHDL_ PTF files are not included in System Capture when migrating a DE-HDL design with local libraries.
3114109 SYSTEM_CAPTURE LICENSING License TIMEOUTALL 3600 not working
2990748 SYSTEM_CAPTURE OPEN_CLOSE_PR Net name bounding box assignment is not retained when the design is open on different machines.
3145716 SYSTEM_CAPTURE PACKAGER beginProp API for physical part instances does not appear to be working
3151471 SYSTEM_CAPTURE PACKAGER System Capture quits unexpectedly while using Assigning Pin Numbers option on a particular component in the design
3135076 SYSTEM_CAPTURE PAGE_BORDER Ghost borders within a design
3141756 SYSTEM_CAPTURE REPORTS RefDes column is empty for a few component pins in concise netlist generated using dsreportgen
3156334 SYSTEM_CAPTURE SMART_PDF Schematic Smart PDF print issue with missing and duplicated images
3163615 SYSTEM_CAPTURE SYMBOL_CREATO PIN TEXT of pin added to hierarchical split symbol is not selectable until System Capture is closed and reopened
3135091 SYSTEM_CAPTURE TOPXP Driver element in Topology Workbench is placed horizontally by default.
3135122 SYSTEM_CAPTURE TOPXP In Topology Workbench, 'Cleanup Canvas' always resets to the extracted view.
3135740 SYSTEM_CAPTURE TOPXP Topology extraction of Diff pair requires clear identification of positive/negative signals.
3139762 SYSTEM_CAPTURE TOPXP Wire jogs at pin components need to be improved.
3146290 SYSTEM_CAPTURE TOPXP Wires are routed under a component in Topology Workbench.
3151588 SYSTEM_CAPTURE TOPXP Connection indicator when drawing a wire in Topology Workbench should be same as in System Capture
3151595 SYSTEM_CAPTURE TOPXP T-Point symbol origin point makes it difficult to place on wire; origin point is on top of T-Point symbol
3154479 SYSTEM_CAPTURE TOPXP Topology Workbench selects a random section of wire after extraction
2766915 SYSTEM_CAPTURE UI Provide User Preference to open new schematic page in the same Tab in System Capture
3082565 SYSTEM_CAPTURE UI Provide ability to open pages in a single tab in system Capture
3121000 SYSTEM_CAPTURE UI Allow opening different pages in single active tab
2913242 SYSTEM_CAPTURE VARIANT_MANAG System Capture Variant Editor needs a Save button
3074437 SYSTEM_CAPTURE VARIANT_MANAG Enhancement Request: Add Save Button in Variant Editor.
3117296 SYSTEM_CAPTURE VARIANT_MANAG Transparency level has no effect on filled color in variant view
3130331 SYSTEM_CAPTURE VARIANT_MANAG Variant with no fill color on the bounding box of the modified part
3156845 SYSTEM_CAPTURE VARIANT_MANAG Unlocking pages in the design causes System Capture to quit unexpectedly
3156866 SYSTEM_CAPTURE VARIANT_MANAG System Capture quits unexpectedly when trying to take an update for the design.
3172736 SYSTEM_CAPTURE VARIANT_MANAG Need a distinctive graphical symbol next to a preferred part in the variant canvas view
3173917 SYSTEM_CAPTURE VARIANT_MANAG System Capture quits unexpectedly while taking update of the project from Pulse
3126636 SYSTEM_CAPTURE WIRING Wires didn't break when multi pin component is dropped on the schematic
3195781 SYS_RELIABILITY STRESS_ANALYS Blank dropdown for temperature setup in Thermal Workflow in System Capture
3155799 TOPXP AURORA Topology Workbench extraction has unnecessary data displayed on the canvas
3172944 TOPXP TOPOLOGY_EXPL Topology Workbench: Copy-paste loses the connection between blocks
