Autodesk Inventor 2019.4.3 Update

Add-Ins - Content Center
Resolved issue where Content Center category icons would go missing after installing Windows 10 update KB4517389. INVGEN-34445
Add-Ins - Tube and Pipe
Resolved an issue where Enter Angle command is not shown in context menu for Tube and Pipe. INVGEN-34287
Assemblies - Derived-Shrinkwrap
Improved stability when updating Derived Part file. INVGEN-34460
Assemblies - Substitute
Resolved an issue where Hole Patching "All" option does not retain Representation View in Derived Assembly. INVGEN-33866
Assemblies - Weldments
Resolved an issue where after running a weldbead report the weldment assembly would no longer have a volume override in the physical properties dialog. INVGEN-34458
Drawings - Annotations
Resolved an issue where dragging a weld symbol resulted in unexpected behavior. INVGEN-29625
Drawings - Annotations - Balloon
Improved performance of call-out symbols (balloons) when drawing is opened with Defer Updates option or is disconnected with the model. INVGEN-34448
Drawings - Views
Resolved issue with the drawing view scale changing unexpectedly when editing, and the scale factor was not listed in the preset value. INVGEN-33861
Resolved issue where drawing files displayed differently when opened in Inventor 2014 and Inventor 2018 or later. INVGEN-33863
Resolved issue causing a performance issue with updating a drawing in R2019. INVGEN-34365
Parts - 2D Sketch
Region Properties are now calculated accurately. INVGEN-23249
Translators - DWG-DXF
Improved material indexing when importing DWG file as DXF. INVGEN-34398
UI - Browser
Improved stability for UI Browser calls in API. INVGEN-33919

Installation Requirements

- Autodesk Inventor 2019 supports -list operating sy.
- Autodesk Inventor 2019 supports Windows 7 SP1 64-bit, Windows 8.1 64-bit and Windows 10 64-bit.
- Windows 7 SP1 requires MS KB update (4019990). If not already present on the machine and/or if MS Updates are disabled, this KB update will need to be applied prior to installing Inventor.
- If you are using Windows 7 on a 64-bit system, please verify that you have the Microsoft fix for user mode callback exceptions KB976038. This fix ensures that Autodesk receives the correct data from Inventor error reports.

System Requirements for Autodesk Inventor 2019 Windows

Operating System
- 64-bit Microsoft Windows 10 Anniversary Update (version 1607 or higher)
- 64-bit Microsoft Windows 8.1
- 64-bit Microsoft Windows 7 SP1 with Update KB4019990
CPU *
Recommended: 3.0 GHz or greater, 4 or more cores
Minimum: 2.5 GHz or greater
Memory
Recommended: 20 GB RAM or more
Minimum: 8 GB RAM for less than 500 part assemblies
Disk Space Installer plus full installation: 40 GB
Graphics
Recommended: 4 GB GPU with 106 GB/S Bandwidth and DirectX 11 compliant
Minimum: 1 GB GPU with 29 GB/S Bandwidth and DirectX 11 compliant
Display Resolution
Recommended: 3840 x 2160 (4K); Preferred scaling: 100%, 125%, 150% or 200%
Minimum: 1280 x 1024
Pointing Device MS-Mouse compliant (3DConnexion 3D Mouse optional)
Network Internet connection for web install with Autodesk Desktop App, Autodesk collaboration functionality, .NET installation, web downloads, and licensing. Network license manager supports Windows Server 2016, 2012, 2012 R2, 2008 R2 and the operating systems listed above.
Spreadsheet Full local install of Microsoft Excel 2010, 2013 or 2016 for iFeatures, iParts, iAssemblies, Global BOM, Parts Lists, Revision Tables, spreadsheet-driven designs and Studio animation of Positional Representations.
64-bit Microsoft Office is required to export Access 2007, dBase IV, Text and CSV formats.
Office 365 subscribers must ensure they have a local installation of Microsoft Excel 2016.
Windows Excel Starter, OpenOffice, and browser-based Office 365 applications are not supported.
Browser Google Chrome or equivalent
.NET Framework .NET Framework Version 4.7 or later. Windows Updates enabled for installation.

For Complex Models, Complex Mold Assemblies, and Large Assemblies (typically more than 1,000 parts)

CPU Type *
Recommended: 3.30 GHz or greater, 4 or more cores
Memory
Recommended: 24 GB RAM or greater
Graphics
Recommended: 4 GB GPU with 106 GB/S Bandwidth and DirectX 11 compliant

Notes:
* Autodesk Inventor is optimized to take advantage of the SSE2 extended instruction sets supported on Pentium 4, AMD Athlon 64, and AMD Opteron processors. Inventor 2019 will not install on computers that do not support SSE2. Several utilities are available on the Internet that report CPUID including supported instructions sets.
