Altair PollEx 6.0.1

PollEx Entity

PollEx Logic
Resolved Issues
- Fixed a bug that the Define Column in the Setting -Settingmenu is not applied properly.

PollEx CAM
Resolved Issues
- Fixed a bug that Tool -Cross Probemenu is deactivated same as the Cross Probe menu is activated when entering right-mouse click after selecting twolayers.
- Fixed an error that View -Panmenu is operated opposite way.

PollEx Basic

PollEx PCB
Resolved Issues
- Modified the default view of the Part Viewerto 3D display when the Unified Part Libraries linked, otherwise to 2D display.
- Fixed a bug that the changed Pad color in the Tool -Net Colormenu is not saved.
- Fixed an error that the reference list does not match with the actual part whensetting the Except Component Definition in the Option -Comp Placing Menu -Input Settingmenu on the Component Arrangement Plan.
- Changed the menu name Run Net Topology Analyzer to Run Net Topology Viewer when accessing right-mouse click from selecting net to avoid the confusion with SI menu.

Real PCB Assembly Viewer
Resolved Issues
- Resolved an issue that tool is crashed when exporting STEP file using ODB++ data.

PollEx CP (Cross Probe)
Resolved Issues
- Resolved an issue that tool is crashed when exporting to Excel with selecting Images option in Global tab under the User Information Setting

PollEx Verification

PollEx DFM
Resolved Issues
- Fixed an error that selected TP Component Group in the checking item Board -Board Spacingis not saved.
- Resolved a problem that the clearance of Test Point and Via is not verified in the checking item Board -Board Spacing.
- Resolved an issue that tool is crashed intermittently when performed the checking item Board -Array Board Size Checkwith imported ODB++ file.
- Fixed a layer display error on the result of the Drill Size -Hole Distancemenu.
- Fixed an error that DFMI file saved in 64-bit version is not read in 32-bit version.

PollEx DFA
Resolved Issues
- Fixed an error that result arrow of the checking itemCollision -Body to Leadon the bottom layer is displayed on top layer.

PollEx DFE
Features
- Added the Consider Match Case when Classification Settingoption in the Option -DFE -DFE Environmentmenu when configuring Net Group to distinguish Net case sensitive.
Resolved Issues
- Modified to check the objects within a specified distance from the specified component when the component is set in Specify Component of the checking item Net -GND Isolation.
- Resolved an issue that not finding the nearest VIA from the designated Pin by changing the VIA searching algorithm in the checking item Power -Connected Via

PollEx DFM+
Features
- Added the Consider Match Case when Classification Settingoption in the Option -DFE+ -Environmentmenu when configuring Net Group to distinguish Net case sensitive.
Resolved Issues
- Modified to load the buffer model automatically that set in the Properties -Partsmenu instead of setting in the Analyze Options column individually of the checking item Timing Skew, Timing Margin, Crosstalk Noise, Crosstalk Jitter and DDR Complianceunder Signal Integrity.

PollEx Analysis

SI (Signal Integrity)
Resolved Issues
- Fixed a bug that the name of opened S-Parameter is not displayed on thelist in the Network Parameter Viewer.

PollEx UPE
UPE (Unified Part Editor)

Resolved Issues
- Improved the menu activation status according to the generating order of Logic Symbol.
- Improved the user convenience that only corresponding partition pins can beassigned instead of showing all partition pins when generating Logic Symbol.
- Improved the menu display in the Package Generation Wizardthat Type 1 and Type 2 are displayed in the figure to prevent the user confusion.
- Resolved an issue that tool is crashed when clicked the Display Button after liked Device Model in the Properties -Device Model Files.
- Fixed a bug that OK button in the Usage Keys and Partitioningwindow is activated before generated Symbol when generating Logic Symbol.
- Fixed an error that zoom-in focus of Package, Footprint and Logic Symbol by using Zoom Windowmenu is displayed wrong area.
- Fixed a bug that the configuredpath column of Output Directory under the Mounter Library is not saved immediately in Environment -Environmentmenu.
- Fixed a bug that "V" mark column in the Footprint Generation Wizarddoes not work to select or deselect all lists.
- Fixed a bug that values when entering new part dimensions are not displayed in the Package Wizard.
- Fixed a bug that the footprint display does not change when moving the keyboard arrows on the Footprint List.
- Fixed a bug that the Footprint List displays the previously selected Footprint when generated new Footprint.
- Fixed a bug that the Partition List displays the previously selected Symbol when generated new Logic Symbol.
- Modified the dropdown menu of the Pin Attachment Sides in the Edit Logic Symbol Configuration Tablein order to generate a Symbol for 1 sided component like a connector.
- Removed unnecessary column in the Package Wizardto avoid user error when entering new part dimensions.
